Application of KCl Organic Salt Polymer Drilling Fluid in Upper Section of Wells Drilled in Block Shuangyushi, West Sichuan
-
摘要: 川西地区双鱼石区块目的层埋藏深,完钻井深在7 000 m以深,上部φ444.5 mm、φ333.4 mm井眼主要采用“空气钻”提速,空气钻井转钻井液如何保证井壁稳定至关重要,在“高效PDC+螺杆”提速方式下优质的钻井液性能也尤其重要。为此,KCl-有机盐聚合物钻井液在KCl、有机盐的共同作用下抑制能力强,能够抑制岩石组分水化分散、膨胀,封堵防塌剂可以快速形成致密泥饼,减少滤液侵入井壁地层,防止“空气钻”后干燥井壁“吸水”引起的井塌;抑制钻屑水化分散,钻井液流变性能稳定、波动小、易调控、现场维护处理简单;钻井液强抑制性、低黏度和切力可提高钻头水马力,减少钻屑在钻头上的吸附,防止钻头泥包现象,减少钻井液中微米、亚微米粒子,有助于提高机械钻速。双探8井等现场应用表明,KCl-有机盐聚合物钻井液确保了“空气钻”井段井壁稳定,顺利钻过沙溪庙组下部(沙一段)、凉高山组、自流井组及须家河组易垮塌地层,井眼畅通、井壁稳定、井径规则、电测顺利、井下安全、钻速较高,满足工程、地质录井需要。Abstract: The target zones in the block Shuangyushi in west Sichuan are buried deep, and wells drilled in that block have completion depth of at least 7 000 m. Air drilling is generally adopted in drilling the upper φ444.5 mm and φ333.4 mm in an effort to drill fast. It is critical to convert air drilling fluid to liquid base drilling fluids, and so is the performance of drilling fluids used in drilling with "high efficiency PDC bit + PDM". KCl organic salt polymer drilling fluid, under the synergistic effect of KCl and organic salts, performs much better in inhibiting the hydration, dispersion and swelling of shaly formations. Plugging agents, on the other hand, quickly form dense mud cakes on the borehole wall, thereby reducing invasion of mud filtrate into formations and preventing the dry borehole wall generated in air drilling from collapsing because of water (mud filtrate) absorption. By minimizing hydration and dispersion of drilled cuttings, mud rheology becomes stable and is easy to maintain. A drilling fluid with good inhibitive capacity, low viscosity and gel strength is helpful in enhancing bit hydraulics and minimizing adsorption of drilled cuttings on drill bit, thereby avoiding bit balling. Reduction in the concentration of micron-sized particles and submicron-sized particles is helpful in ROP enhancement. Field application of the drilling fluid in well Shuangtan-8 showed that the use of KCl-organic salt polymer drilling fluid ensured the borehole stability of the air drilling section, helped drilling through the bottom of the Shaximiao formation (Shayi member), Lianggaoshan formation, Ziliujing formation and Xujiahe formation successfully. During drilling operations, tripping of drilling string was smooth, borehole wall was stable, electric wireline logging was conducted favorably, no downhole problems took place, and penetration arte was satisfactory. The use of the KCl-organic salt polymer drilling fluidhas satisfied the needs of engineering and mud logging.
-
[1] 鄢捷年. 钻井液工艺学[M]. 石油大学出版社, 2001,5. YAN Jienian. Drilling fluid technology[M].China University of petroleum Press,2001,5. [2] 徐同台.21世纪初国外钻井液和完井液技术[M]. 石油工业出版社, 2004,4. XU Tongtai. 21th century drilling and well-completion fluid[M].Petroleum Pndustry Press,2004,4. [3] 步宏光, 张民立, 唐世忠. 有机盐钻井液技术在大港油田水平井的研究与应用[J]. 钻采工艺, 2011,34(1):83-85.BU Hongguang, ZHANG Minli,TANG Shizhong. Research and application of organic sale drilling fluid in Dagang oil field horizontal wells[J].Drilling & Production Technology, 2011,34(1):83-85. [4] 王兰,陈俊斌, 刘宇凡. 有机盐钻井液在磨溪11井的应用[J]. 钻采工艺, 2014,37(1):102-104.WANG Lan, CHENG Junbin,LIU Yufan. Application of organic sale drilling fluid in Mo Xi 11 Well[J]. Drilling & Production Technology, 2014,37(1):102-104. [5] 李向碧,郑有成,王兰.KCl-有机盐钻井液在高石梯-磨溪区块上部井段钻井提速中的应用[J]. 天然气工业, 2014,34(3):121-125.LI Xiangbi, ZHENG Youchen, WANG Lan. Application of KCl-organic salt drilling fluids to the ROP enhancement in the top section of wells in the Gaoshiti-Moxiblock, Sichuan Basin[J]. Natural Gas Industry, 2014,34(3):121-125. [6] 孙长健,张仁德,漆林. 气体钻井转换钻井液保持井壁稳定技术[J]. 钻采工艺, 2010,33(2):15-16.SUN Changjian, ZHANG Rende,QI Lin. Enhancing wellbore stability technique while mud system transformation in gas drilling[J]. Drilling & Production Technology,2010,33(2):15-16. [7] 覃勇,黄平,万伟. 川中地区上部地层钻井液增速技术[J]. 钻井液与完井液, 2015,32(3):96-98.QIN Yong, HUANG Ping, WAN Wei. Drilling fluid to accelerate drilling in top formations in mid-Sichuan[J]. Drilling Fluid & Completion Fluid,2015,32(3):96-98. [8] 郑述权,张帆,钟广荣.乐山-龙女寺古隆起震旦系超深井快速钻井技术[J]. 天然气工业, 2013,33(7):74-79.ZHENG Shuquan,ZHANG Fan,ZHONG Guangrong. Fast drilling technology of ultra deep wells in the Sichuan basin reservoirs in the Leshan-Longnusi palaeohigh, Sichuan Basin[J]. Natural Gas Industry, 2013,33(7):74-79. -
