Study and Application of a Corrosion Inhibitor Used in Self-diverting Acid
-
摘要: 目前在筛管完井方式的水平井中，酸化中采用转向酸酸液体系是实现均匀布酸最便捷、有效的方法，缓蚀剂是转向酸酸化安全实施的重要保障，但是目前已有的缓蚀剂大多与自转向酸体系不配伍，影响转向效果，且缓蚀效果大大下降。针对此问题，研制出一种自转向酸用缓蚀剂ZXHS，并对其进行了基本性能评价。由评价结果可知，加有ZXHS的自转向酸在90℃下的静态腐蚀速率可控制在5 g/（m2wh）以内，在120℃下动态腐蚀速率可控制在20 g/（m2wh）以内，均可达到行业一级品要求。加入ZXHS后自转向酸转向黏度仍可保持在160 mPa·s以上，因此ZXHS的缓蚀效果良好并且不影响自转向酸的转向性能。ZXHS在大港油田和伊拉克艾哈代布油田进行了现场应用，施工效果良好。Abstract: Horizontal wells completed with screen pipes are generally acidized with diverting acids, a method with which acid can be evenly distributed in a target zone with ease and effectively. Corrosion inhibitors, an important insurance for safe operation of acidization with diverting acids, are not compatible with most of the self-diverting acids presently in use, therefore the diverting action is negatively affected, and the corrosion inhibitive efficiency is remarkably reduced. A self-diverting acid, ZXHS, has recently been developed aimed at addressing these problems. Laboratory evaluation showed that the corrosion rate of ZXHS can be controlled within 5 g/(m2ws) at 90℃, and within 20 g/(m2ws) at 120℃, all conforming to the industrial requirement of "Grade 1" product. A selfdiverting acid treated with ZXHS had viscosity of greater than 160 mPa·s, and good corrosion inhibition and diverting performancecan be achieved with the diverting acid. ZXHS has been used in Dagang oilfield and Al-Ahdab oilfield (Iraq), gaining good operation achievements.
-
[1] FORD,JASON.At the forefront of the corrosion inhibitor sphere[J].Engineer,2016,297(7877):12. [2] YOSHIMOTO K, NOZAWA M, MATSUMOTO S, et al.Studies on the adsorption property and structure of polyamine-ended poly(ethylene glycol) derivatives on a gold surface by surface plasmon resonance and angleresolved x-ray photoelectron spectroscopy[J].Langmuir, 2009,25(20):12243-12249. [3] SHI HONG,XYU BIN.Electrochemical and theoretical studies of 1-alkyl-2-substituted benzimidazoles as corrosion inhibitors for carbon steel surface in hcl medium[J].Chinese Journal of Structural Chemistry. 2016,35(12):1829-1839. [4] 刘倍贝,周福建,胡大鹏. 黏弹性表面活性剂转向酸缓蚀剂研究进展[J]. 石油与天然气化工,2015,44(5):86-89.LIU Beibei,ZHOU Fujian,HU Dapeng.Research progress of corrosion inhibitor for viscoelastic surfactantbased self-diverting acid[J].Chemical Engineering of Oil & Gas,2015, 44(5):86-89. [5] 高尚,符扬洋,孟祥海,等. 新型砂岩自转向酸体系的研究与应用[J]. 钻井液与完井液,2017,34(2):121-125.GAO Shang,FU Yangyang,MENG Xianghai,et al. Study and application of a new self-diverting acid for use in sandstone fracturing[J].Drilling Fluid & Completion Fluid,2017,34(2):121-125. [6] 刘祥,古朋,李善建. 环保型酸化缓蚀剂MCA-Ⅰ的研制及性能评价[J]. 材料保护,2017,50(4):73-76.LIU Xiang,GU Peng,LI Shanjian.Development and performance evaluation of environmentally friendly MCA-Ⅰ corrosion inhibitor for acidification[J].Materials Protection,2017,50(4):73-76. [7] 刘志辉,王霞,吴艺琛. 曼尼希碱型酸化缓蚀剂研究进展[J]. 应用化工,2014,1:148-150. LIU Zhihui,WANG Xia,WU Yichen.Research progress of mannich base inhibitors for acidification[J]. Applied Chemical Industry,2014,1:148-150. [8] 杨秀芳,唐敏敏,马养民. 曼尼希碱缓蚀剂在盐酸中对N80钢缓蚀性能[J]. 表面技术,2017,46(1):175-181.YANG Xiufang,TANG Minmin,MA Yangmin. Mannich base as corrosion inhibitor for N80 steel in hci solution[J].Surface Technology,2017,46(1):175-181. [9] 何春明, 陈红军, 刘岚, 等.VES自转向酸变黏机理研究[J]. 钻井液与完井液, 2010, 27(4):84-86.HE Chunming,CHEN Hongjun,LIU Lan,et al. A study on diverting mechanism of VES self-diversion acid[J].Drilling Fluid & Completion Fluid,2010,27(4):84-86. [10] 王艳丽. 新型高性能转向酸的制备及性能评价[J]. 钻井液与完井液,2016,33(6):111-115.WANG Yanli.Preparation and evaluation of a new high performance diverting acid[J].Drilling Fluid & Completion -
