Development of a New Low Density High Strength Hydraulic Fracturing Proppant
-
摘要: 在油气田水力压裂中使用性能优异的低密度陶粒支撑剂,不仅可以解决支撑剂在裂缝内输送过程中的沉降问题,提高有效支撑裂缝的长度和导流能力,而且能够降低对压裂流体性能的要求,减小施工泵送功率,降低施工风险。以低品位铝矾土(A12O3含量低于70%)和工业废弃物粉煤灰为主要原料,配以特殊辅料,按照一定比例混合粉磨、经制粒成球及高温煅烧等特殊工艺处理,研制出低密度高强度陶粒支撑剂,制备的粒径为0.45~0.9 mm样品体积密度为1.40~1.55 g/cm3,视密度为2.75 g/cm3左右,在52 MPa闭合压力下破碎率低于5.0%,性能优异,在低渗致密油气田和页岩气增产开发中具有广阔的应用前景。Abstract: The use of high performance low density ceramic proppants in reservoir fracturing not only avoids the settling of proppant particles during their migration in fractures, thereby effectively lengthening the fracturespropped and enhancing the fluid conductivity of the fractures, it also helps relax the requirements for the performance of fracturing fluid, and reduce the pumping power required and minimize operating risks. This paper discusses the preparation of a low density high strength ceramic proppant from a low-grade bauxite (containing less than A12O3) and fly ash, an industrial waste. Mixtures of the bauxite, the fly ash and some special accessories in a certain ratio were ground, and then calcined at high temperatures to form spherical ceramic particles with low density and high strength. The proppant prepared had particle sizes between 0.45 mm and 0.9 mm, bulk density between 1.40 g/cm3 and 1.55 g/cm3, and apparent density of ca. 2.75 g/cm3. In laboratory test, only 5% of the proppant particles were broken into pieces under a closure pressure of 52 MPa. This ceramic proppant, because of its superior performance, will find wide application in low permeability reservoir development and shale gas reservoir stimulation.
-
Key words:
- Proppant /
- Hydraulic fracturing /
- Low density /
- High strength /
- Bauxite /
- Fly ash
-
[1] 渑池县方圆陶粒砂厂. 高强度陶粒支撑剂及其制备方法:中国,200410010272.6[P].2004-5-18.Mianchi Fangyuan Ceramic Sand factory.High performance ceramic proppants and its preparation method:China,200410010272.6[P].2004-5-18. [2] 蔡宝中,徐海升.高强度耐酸支撑剂的研制与开发[J].西安石油大学学报(自然科学版),2006,21(6):76-79. CAI Baozhong,XU Haisheng.Development of a highstrength acid-resisting proppant.[J].Journal of Xi'an Shiyou University(Naturnal Science Edition),2006,21(6):76-79. [3] 王晋槐,赵友谊,龚红宇,等. 石油压裂陶粒支撑剂研究进展[J]. 硅酸盐通报,2010,29(3):633-636.WANG Jinhuai,ZHAO Youyi,GONG Hongyu, et al.Advance of ceramic proppants for oil hydraulic fracture[J].Bulletin of the Chinese Ceramic Society, 2010,29(3):633-636. [4] Abou-Sekkina Morsy M,Abo-El-Encin Salah A. Phase compositionof bauxit-based refractory castables[J]. Ceramics International,2011(37):411-418 [5] SY/T 5108-2014水力压裂和砾石充填作业用支撑剂性能测试方法[S]. 北京:石油工业出版社,2014. SY/T 5108-2014,Measurement of Properties of Proppants used in Hydraulic Fracturing and Gravel-packing Operations[S]. Beijing:Petroleum Industry Press. [6] 黄彩贺,卢拥军,邱晓惠,等. 支撑剂单颗粒沉降速率与线性胶压裂液黏弹性关系[J]. 钻井液与完井液, 2015,32(6):72-77.HUANGCaihe,LU Yongjun,QIU Xiaohui,et al. Study on relationship between sedimentation rate of single proppant particle and viscoelasticity of linear colloid fracturing fluid[J]. Drilling Fluid & Completion Fluid, 2015,32(6):72-77. [7] 马志武,门艳萍,朱海涛. 低渗透油藏压裂用支撑剂质量影响因素分析[J]. 石油工业技术监督,2012(7):6-9. MA Zhiwu,MEN Yanping,ZHU Haitao,et al. Analysis of factors influencing the quality of fracturing propping agents in low permeability reservoir[J]. Technology Supervision in Petroleum Industry,2012(7):6-9. [8] 王晓蕾. 支撑剂嵌入及其对裂缝导流能力影响实验研究[J]. 内蒙古石油化工,2015(13):153-155. WANG Xiaolei. Proppant mmbed and its effect on fracture conductivity study[J].Inner Mongolia Petrochemical Industry,2015(13):153-155. [9] 贾新勇. 我国支撑剂的发展应用及现状[J]. 企业技术开发,2011,30(9):105-106.JIA Xinyong.The applications and agent status of propping agent in China[J].Technological Development of Enterprise,2011,30(9):105-106. -
