高石梯-磨溪区块高压气井尾管固井技术

宋有胜; 邹建龙; 赵宝辉; 刘爱萍

doi:10.3969/j.issn.1001-5620.2017.02.020

高石梯-磨溪区块高压气井尾管固井技术

doi: 10.3969/j.issn.1001-5620.2017.02.020

中国石油集团海洋工程有限公司渤星公司·中国石油集团钻井工程重点实验室固井技术研究室·油气钻井技术国家工程实验室固井技术研究室, 天津 300451

基金项目:

国家科技重大专项课题"深井超深井优质钻井液与固井完井技术研究"（2016ZX05020-004）和中国石油天然气集团公司课题"复杂工况条件下固井密封力学机理及控制技术研究"（2016A-3904）。

详细信息

作者简介:
宋有胜,高级工程师,1966年生,毕业于天津大学应用化学系,现在从事固井技术研究和应用工作。电话(022)66310307/13920263721;E-mail:songys@cnpc.com.cn。

中图分类号: TE256.3
计量
- 文章访问数: 768
- HTML全文浏览量: 198
- PDF下载量: 135
- 被引次数: 0
出版历程
- 收稿日期: 2016-11-25
- 刊出日期: 2017-03-31

Liner Cementing the high pressure gas wells in the Block Gaoshiti-Moxi

Boxing Subsediary of CNPC Offshore Engineering Company Limited Research Center of Well Cementing Technology, CNPC Key Laboratory of Drilling Engineering Research Center of Well Cementing Technology, National Engineering Laboratory of Oil & Gas Drilling Technology, Tianjin 300451

摘要

摘要: 针对西南油气田高石梯-磨溪区块高压气井φ177.8 mm尾管固井遇到的气层活跃、安全密度窗口窄、流体相容性差及高温大温差等问题，制定了相应的固井技术措施。开发了适合高温大温差固井的自愈合防窜高密度水泥浆体系，并进行了室内研究。结果表明：该体系密度为2.0~2.8 g/cm³，现场一次混配可达2.6 g/cm³以上；适应温度为常温~180℃；浆体的上下密度差不大于0.05 g/cm³；失水量不大于50 mL；稠化时间与缓凝剂掺量具有良好的线性关系，稠化过渡时间不大于10 min；静胶凝强度过渡时间不大于20 min；24 h抗压强度大于10 MPa，水泥石顶部48 h抗压强度大于3.5 MPa，低温下强度发展快，形成的水泥石体积稳定不收缩，具有类似韧性水泥的力学性能；遇油气产生体积膨胀，保证了界面胶结质量和密封完整性，降低了固井后发生气窜的风险。该固井技术在高石X井和高石Y井中进行了应用，固井优质率和合格率得到较大幅度提高，水泥环后期不带压，获得良好应用效果。
- 天然气井 /
- 固井 /
- 自愈合防窜高密度水泥浆 /
- 气窜 /
- 漏失 /
- 大温差 /
- 安岳气田
Abstract: In cementing the φ177.8 mm liner string in high pressure gas wells in the Block Gaoshiti-Moxi of southwest oilfield, problems such as active gas zones, narrow drilling windows, poor compatibility of fluids and large temperature difference at high temperatures, were encountered. Technical measures were prepared to deal with these problems, and a self-healing anti-channeling high density cement slurry was developed for cementing wells with large temperature difference at high temperatures. Laboratory study of the cement slurry showed that the cement slurry had density between 2.0 g/cm³ and 2.8 g/cm³, and in field application, the cement slurry can be prepared to have a density of 2.6 g/cm³ in one mixing circulation. This cement slurry functioned at temperatures between room temperature and 180℃. Differences between the density of the top and bottom of cement slurry column was less than or equal to 0.05 g/cm³. The fluid loss of the cement slurry was less than or equal to 50 mL. The thickening time had good linear relationship with the concentration of retarders, and the transit time for the thickening of the cement slurry was not longer than 10 min. The maximum transit time of the gel strengths of the cement slurry was 20 min. The 24-hour compressive strength of the set cement was greater than 10 MPa, and the 48-hour compressive strength of the cement top was greater than 3.5 MPa. The strength of the cement slurry developed fast at low temperatures. The set cement formed had stable non-shrinking volume, possessing a mechanical performance that is similar to that of tough cement. The cement slurry expanded when in contact with oil and gas, ensuring the quality of bonding between cement sheath with casing string and borehole wall, and the integrity of sealing, which in turn mitigating the risk of gas channeling after cementing job. High quality of cementing job with this cement slurry was obtained in cementing the well Gaoshi-X and the well Gaoshi-Y, with no pressure developed in the annular space after cementing.
- Gas well /
- Well cementing /
- Self-healing anti-channeling high density cement slurry /
- Gas channeling /
- Lost circulation /
- Large temperature difference /
- Block gaoshiti-moxi

HTML全文

参考文献(10)

[1]	赵常青,张军,孙海芳,等.M-G区块高压气井尾管固井技术[J].钻采工艺,2014,37(2):12-15. ZHAO Changqing,ZHANG Jun,SUN Haifang,et al.Liner cementing technology of high-pressure gas well in M-G block[J].Drilling and Production Technology, 2014,37(2):12-15.
[2]	黄柏宗.紧密堆积理论的微观机理及模型设计[J].石油钻探技术,2007,35(1):5-12. HUANG Baizong.The microscopic mechanism and model design of the close packing theory[J]. Petroleum Drilling Techniques,2007,35(1):5-12.
[3]	赵宝辉,邹建龙,刘爱萍,等.适用于长封固段固井的新型缓凝剂[J]. 钻井液与完井液,2011,28(增刊):10-12. ZHAO Baohui,ZOU Jianlong,LIU Aiping, et al. A novel retarder of oil well cement for the long cementing interval with significant temperature difference[J].Drilling Fluid and Completion Fluid,2011 ,28(S):10-12.
[4]	赵宝辉,邹建龙,刘爱萍,等.新型缓凝剂BCR-260L性能评价及现场试验[J]. 石油钻探技术,2012, 40(2):55-58. ZHAO Baohui,ZOU Jianlong, LIU Aiping, et al.Performance evaluation and aplication of novel retarder BCR-260L[J].Petroleum Drilling Techniques,2012,40(2):55-58.
[5]	赵宝辉,邹建龙,石凌龙,等.油气井固井用自愈合剂研究与现场应用[C].2016年固井技术研讨会论文集.合肥:石油工业出版社,2016:444-451. ZHAO Baohui,ZOU Jianlong,SHI Linglong,et al. Research and application of self-healing agent for well cementing[C].Technical Papers for 2016 Cementing Technology Seminar,Hefei:Petroleum Industry Press, 2016 :444-451.
[6]	赵宝辉,石凌龙,邹建龙,等.自愈合防窜水泥在G103井177.8mm尾管固井中的应用[C].2015年度钻井技术研讨会暨第十五届石油钻井院(所)长会议论文集.北京:石油工业出版社,2015:265-269. ZHAO Baohui,SHI Linglong,ZOU Jianlong,et al. Application of self-healing anti-channeling slurry in 177.8 mm liner cementing of G103[C]. Technical Papers for 2015 Drilling Technology Seminar.Beijing:Petroleum Industry Press,2015:265-269.
[7]	张华,王大权,胡霖. 安岳气田磨溪009-4-X2井尾管固井技术[J]. 钻井液与完井液,2016,33(3):84-88. ZHANG Hua,WANG Daquan,HU Lin.Line r cementing technology for well Moxi 009-4-X2 in block Anyue[J].Drilling Fluid and Completion Fluid,2016, 33(3):84-88.
[8]	和建勇, 党冬红, 刘艳军, 等. 南堡36-P3001井高温小间隙尾管固井技术[J]. 石油钻采工艺, 2014, 36(1):48-50. HE Jianyong, DANG Donghong, LIU Yanjun, et al. High temperature small annular space liner cementing techniques of Nanpu 36-P3001 well[J]. Oil Drilling & Production Technology, 2014, 36(1):48-50.
[9]	田宝振,李清洁,覃毅,等. 塔中碎屑岩井自愈合水泥浆固井技术[J]. 钻井液与完井液,2016,33(6):84-90. TIAN Baozhen,LI Qingjie,QIN Yi,et al.Cementing wells penetrating clastic rocks with self-healing cement in block tazhong[J]. Drilling Fluid and Completion Fluid, 2016,33(6):84-90.
[10]	于永金,靳建洲,齐奉忠. 功能性固井工作液研究进展[J]. 钻井液与完井液,2016,33(4):1-7. YU Yongjin,JIN Jianzhou,QI Fengzhong. Progress of study on functional cementing fluids[J]. Drilling Fluid & Completion Fluid,2016,33(4):1-7.
