粒径对油井水泥水化热及力学性能的影响

黄锦; 姚晓; 姜祥; 王志国; 吕志国; 李志远

doi:10.3969/j.issn.1001-5620.2017.02.016

粒径对油井水泥水化热及力学性能的影响

doi: 10.3969/j.issn.1001-5620.2017.02.016

黄锦¹,
姚晓^1,2, ,,
姜祥¹,
王志国³,
吕志国³,
李志远³

1. 南京工业大学材料科学工程学院, 南京 210023;
2. 江苏先进生物与化学制造协同创新中心, 南京 210023;
3. 中石化华东石油工程有限公司钻井处, 江苏扬州 210019

基金项目:

江苏高校品牌专业建设工程资助项目（PPZY2015B128）；江苏高校优势学科建设工程资助项目（PAPD）。

详细信息

作者简介:
黄锦,在读硕士研究生,研究方向为油田材料化学及胶凝材料。电话18260021562;E-mail:18260021562@163.com。

通讯作者:
姚晓,E-mail:yaoxiao@njtech.edu.cn。

中图分类号: TE256.6
计量
- 文章访问数: 798
- HTML全文浏览量: 199
- PDF下载量: 130
- 被引次数: 0
出版历程
- 收稿日期: 2017-01-05
- 刊出日期: 2017-03-31

Effects of Particle Size on Hydration Heat and Mechanical Performance of Cement

1. College of Material Science and Engineering, Nanjing University of Technology, Nanjing 457001;
2. The Synergetic Innovation Center for Advanced Materials, Nanjing 210023;
3. Department of Drilling, Sinopec East China Petroleum Engineering Co. Ltd., Yangzhou, Jiangsu 210019

摘要

摘要: 油井水泥的粒径与其性能和用途密切相关，考察了3种粉磨方式下不同粒径分布油井水泥浆的性能。利用等温量热仪（ICC）、X射线衍射分析仪（XRD）、压汞仪（MIP）和扫描电镜（SEM）分别测试了不同粒径水泥颗粒早期水化放热速率、水泥石水化产物、孔结构及颗粒微观形貌。结果表明，物理粉磨方法只能将颗粒超细化，不能纳米化；相同水灰比的水泥浆，其原料颗粒粒径分布对浆体密度、水化产物无明显影响。但随水泥颗粒粒径的减小，浆体稠化时间缩短、流变性变差、析水率降低，稳定性增加。同时，超细水泥颗粒反应活性增强，水化放热量及放热速率增加，水灰比为0.5的0.013mm超细水泥（MC1000-0.5）24 h累积水化放热量较水灰比为0.5的普通G级水泥（G-0.5）提高了91.03%。在短期内生成了更多的水化产物，提高了水泥石早期强度及抗渗性能，且降低了水泥石的总孔隙率，水灰比为0.7的0.013 mm超细水泥（MC1000-0.7）水泥石的1 d龄期抗压、抗折强度较水灰比为0.7的普通G级水泥（G-0.7）分别提高了226.32%、153.13%，其28 d龄期总孔隙率及渗透率较G-0.7水泥石分别降低了10.1%及41.7%，但后期抗压强度增长幅度不大。
- 挤水泥 /
- 超细水泥 /
- 纳米水泥 /
- 粒径分布 /
- 水化热 /
- 力学性能 /
- 粉磨制备
Abstract: The particle sizes of oil well cement are closely related to its performance and use. Oil well cements of different particle size distribution obtained with three grinding methods have been studied for their early hydration exothermic rate (rate of hydration heat liberation), hydration product of set cement, pore structure and the micro-morphology of particles using ICC, XRD MIP and SEM experiments. It was shown that physical grinding cannot produce nano particles; it can only produce ultra-fine particles. Particles size distributions of cement slurries with the same water/cement ratio had no appreciable effect on the density of the slurries and the hydration products. On the other hand, cement slurries with smaller particle sizes had shortened thickening time, poor rheology, reduced percentage of free water, and better stability. Meanwhile, ultra-fine cement particles had enhanced hydration reactivity and higher hydration heat and hydration exothermic rate. The cumulative hydration heat released in 24 hours of a 0.013 mm ultra-fine cement (MC1000-0.5) was 91.03% higher than that of conventional class G cement (G-0.5) at the same water/cement ratio of 0.5. The ultra-fine particle cement produced more hydration products in a short period, and the set cement had improved early strength and impervious performance, and reduced total porosity. The set cement of a 0.013-mm ultra-fine cement (MC1000-0.7) had 1-d compressive strength and flexural strength that were 226.32% and 153.13% higher than those of the class G cement (G-0.7) respectively at the same water/cement ratio of 0.7. The MC1000-0.7set cement had 28-d total porosity and permeability that were 10.1% and 41.7% lower respectively than those of the G-0.7 set cement, while the late-stage compressive strength of the MC1000-0.7 set cement only slightly increased.
- Squeeze cementing /
- Ultra-fine cement /
- Oil well cement /
- Particle size distribution /
- Hydration heat /
- Mechanical performance /
- Grinding method

HTML全文

参考文献(10)

[1]	刘明峰,熊腊生,赵福祥,等. 文23-6J救援井挤水泥技术[J]. 钻井液与完井液, 2015, 32(4):101-103. LIU Mingfeng,XIONG Lasheng,ZHAO Fuxiang,et al.Cementing of relief well for well Wen23-6J[J].Drilling Fluid & Completion Fluid,2015,32(4):101-103.
[2]	KHOR Y Y,LSMAIL M S,et al.Breathing second life into an old well through coiled tubing cement squeeze for brownfields in malaysia[C].SPE168232, 2014.
[3]	DEOLARTE C,VASQUEZ J,SORIANO E.Successful combination of an organically cross-linked polymer system and a rigid-setting material for conformance control in mexico[J].SPE Prod & Oper,2009,24(4):522-529.
[4]	王超,王野,任强,等. 超细水泥在储气库老井封堵中的研究与应用[J]. 钻井液与完井液,2011,28(5):54-56. WANG Chao,WANG Ye,REN Qiang,et al.Research and application of superfine cement in job of old well plugging back in underground gas storage facilities[J]. Drilling Fluid & Completion Fluid,2011,28(5):54-56.
[5]	CHEN J J,KWAN A K H.Superfine cement for improving packing density, rheology and strength of cement paste[J].Cement and Concrete Composites, 2012,34(1):1-10.
[6]	DE LA ROIJ R,EGYDD C.Nano-engineerde oil well cement improvees flexibility and compressive strength[C]. SPE 156501,2012.
[7]	黄新,袁润章,龙世宗,等. 水泥粒径分布对水泥石孔结构与强度的影响[J]. 硅酸盐学报, 2004, 32(7):888-891. HUANG Xin,YUAN Runzhang,LONG Shizong,et al. Influence of cement particle size distribution on pore structure and strength of the cement paste[J].Journal of the Chinese Ceramic Society,2004,32(7):888-891.
[8]	王冲,张洪波,杨长辉,等. 水泥细度对水泥水化及混凝土早期开裂影响[J]. 建筑材料学报,2013,16(5):853-857. WANG Chong,ZHANG Hongbo,YANG Changhui, et al. Influence of cement fineness on hydration of cement and early-age cracking of concrete[J].Journal of Building Materials,2013,16(5):853-857.
[9]	侯力伟. 大庆油田低密度低温防窜水泥浆体系[J]. 钻井液与完井液,2016,33(4):79-82. HOU Liwei.Low density low temperature anti-channeling cement slurry used in Daqing oilfield[J].Drilling Fluid & Completion Fluid,2016,33(4):79-82.
[10]	步玉环,侯献海,郭胜来. 低温固井水泥浆体系的室内研究[J]. 钻井液与完井液,2016,33(1):79-83. Bu Yuhuan,Hou Xianhai,Guo Shenglai,et al.Study on low temperature cementing slurry[J].Drilling Fluid & Completion Fluid,2016,33(1):79-83.
