直接返排钻井完井液储层保护机理分析

张伟国; 许明标; 由福昌

doi:10.3969/j.issn.1001-5620.2017.01.016

直接返排钻井完井液储层保护机理分析

doi: 10.3969/j.issn.1001-5620.2017.01.016

1. 中海石油深圳分公司深水工程技术中心, 广东深圳 518067;
2. 长江大学非常规油气湖北省协同创新中心, 武汉 430100

基金项目:

中国海洋石油总公司重大科研专项（CNOOC-KJ125ZDXM07LTD）资助。

详细信息

作者简介:
张伟国,高级工程师,现在主要从事海上钻完井技术管理工作。电话(0755)26022229;E-mail:zhangwg@cnooc.com.cn。

中图分类号: TE254.3
计量
- 文章访问数: 574
- HTML全文浏览量: 162
- PDF下载量: 300
- 被引次数: 0
出版历程
- 收稿日期: 2016-11-03
- 刊出日期: 2017-01-31

Analysis of Reservoir Protection Mechanism by Direct Drilling Fluid Flowback

1. Technical Center of Deepwater Engineering, Shenzhen Branch Comnpany, CNOOC, Shenzhen, Guangdong 518067;
2. Hubei Cooperative Innovation Center of Unconventional Oil and Gas, Yangtz University, Wuhan, Hubei 430100

摘要

摘要: 水平井裸眼完井是一种最大限度提高储层开采能力的方式，海上油田常采用无固相钻井完井液并辅以破胶完井的方式来完成钻完井作业。直接返排钻井完井液是在此基础上开发的，对其在参数设计、材料选择、完井工艺等方面进行了分析与评价，并分析了其储层保护机理。该体系基本组成为海水+纯碱/烧碱+流型调节剂VIS+淀粉降滤失剂STARFLO+可溶盐+高纯粒径匹配碳酸钙MBA，3种功能材料均能够被0.3% HTA隐形酸螯合剂溶液液化，液化后无任何残留，使井筒内及近井地带的泥饼全部转化为清洁盐水，MBA由5种不同粒径的碳酸钙复配而成，且和淀粉可以达到互相“镶嵌”的作用，使泥饼更加致密。通过实验评价，该钻井完井液的低剪切速率黏度控制在30 000 mPa·s左右，具有最佳防止污染和返排的能力，且渗透率恢复值最高，可抗15%左右钻屑污染，渗透率恢复值大于80%。该体系在南海东部3个油田、1个气田已应用12口井，井底最高温度为60~130℃，密度最高为1.20 g/cm³，3口井属于低孔渗油藏，9口井属于中、高孔渗油藏，钻井过程顺利。该技术简化了完井方式，节省了作业时间与费用，并具有较好的储层保护效果。
- 钻井完井液 /
- 防止储层损害 /
- 水平井 /
- 裸眼完井 /
- 海上钻井
Abstract: Horizontal well open hole completion is a way of well completion to maximize well production rate. In offshore drilling, well completion is generally done with solids-free drill-in fluid, supplemented with gel-breaking well completion. Direct flowback of drill-in fluid is a technology developed on the basis of this way of well completion. In this paper, parameter design, additive selection and well completion technique were systematically analyzed and evaluated, and the mechanism of reservoir protection of this technology was also analyzed. The composition of the drill-in fluid is as follows:seawater+soda ash/caustic soda+rheology modifier VIS+starch filter loss reducer STARFLO+soluble salt (shale inhibition and mud weight)+high purity sized calcium carbonate MBA. The three functional additives of the formulation can all be liquefied by 0.3% HTA (a chelating agent) solution. The liquefaction of the additives left no residue and the mud cakes in the wellbore and near the borehole wall were all converted to clear saltwater. MBA is a mixture of calcium carbonate powders with five particle sizes. The particles of MBA can be "inter-inserted" with starch to form a mud cake that is much denser. Laboratory experiment has shown that the drill-in fluid had low-shear-rate viscosity of around 30,000 mPa·s, optimum contamination-resistance and flowback ability, and the highest permeability return. After contaminated with 15% drill cuttings, the drill-in fluid still had permeability return of more than 80%. This drill-in fluid was used in twelve wells in three oil fields and one gas field in the east of South China Sea. The maximum temperature at the hole bottom was 60-130℃, and the highest mud density was 1.20 g/cm³. Three of the twelve wells penetrated low porosity low permeability reservoirs and the rest nine wells penetrated reservoirs with medium to high porosity and permeability. The drilling operation was successful. The use of this technology simplified the process of well completion, saved operational time and cost, and protected the reservoirs from being damaged.
- Drill-in fluid /
- Prevent reservoir damage /
- Horizontal well /
- Open hole completion /
- Offshore drilling

HTML全文

参考文献(12)

[1]	马美娜,许明标. 一种PRD钻井液性能评价[J]. 天然气勘探与开发,2006,29(2):53-55. MA Meina,XU Mingbiao. Property evaluation of PRD drilling fluid[J].Natural Gas Exploration & Development, 2006,29(2):53-55.
[2]	马美娜, 许明标, 唐海雄, 等. 有效降解PRD钻井液的低温破胶剂JPC室内研究[J]. 油田化学,2005,22(4):289-291. MA Meina,XU Mingbiao,TANG Haixiong, et al. Low temperature gel breaker JPC for breakdown of gelled PRD polymer drilling-in fluid in borehole bottom[J].Oilfield Chemistry, 2005,22(4):289-291.
[3]	程鑫桥, 舒福昌, 李蔚萍,等.一种用于PRD钻井液的缓释破胶剂[J]. 钻井液与完井液,2010, 27(1):33-35. CHENG Xinqiao,SHU Fuchang,LI Weiping,et al.A controlled release of gel breaker used in the PRD drilling fluid[J]. Drilling Fluid & Completion Fluid,2010, 27(1):33-35.
[4]	卢淑芹, 姜薇, 陈金霞,等. 南堡潜山油气层钻井完井液技术[J]. 钻井液与完井液,2015, 32(6):18-21. LU Shuqin, JIANG Wei, CHEN Jinxia, et al. Drilling fluid technology for drilling Nanpu buried hill oil reservoir[J]. Drilling Fluid & Completion Fluid,2015, 32(6):18-21.
[5]	韦红术,张俊斌,张伟国,等. 泥饼可液化处理的UltraFLO钻井完井液[J]. 钻井液与完井液,2015,32(4):37-39. WEI Hongshu, ZHANG Junbin,ZHANG Weiguo, et al.UltraFlo drill-in fluid[J].Drilling Fluid & Completion Fluid,2015, 32(4):37-39.
[6]	赵峰,唐洪明,张俊斌,等. LF13-1油田PRD钻完井液体系储层保护效果优化研究[J]. 特种油气藏,2010, 17(6):88-90. ZHAO Feng, TANG Hongming, et al. Optimization of reservoir protection effect of PRD drilling and completion fluid system for LF13-1 oilfield[J].Special Oil and Gas Reservoirs, 2010,17(6):88-90.
[7]	ABRAMS A. Mud design to minimize rock impairment due to particle invasion[J]. JPT, 1977, 29(3):585-592.
[8]	王建华,鄢捷年,郑曼,等. 理想充填暂堵钻井液室内研究[J]. 石油勘探与开发,2008,35(2):230-233. WANG Jianhua, Yan Jienian,Zheng Man, et al. Laboratory study of ideal packing approach applying to high permeability sandstones[J].Petroleum Exploration and Development, 2008,35(2):230-233.
[9]	邱正松, 张世锋, 黄维安, 等. "多级孔隙最优充填暂堵方法"与现场试验[J].石油钻探技术, 2012, 40(5):17-21. QIU Zhengsong,ZHANG Shifeng, HUANG Weian,et al. Temporary plugging and field testing with "optimum filling for multi-stage pores" method[J].Petroleum Drilling Techniques, 2012,40(5):17-21.
[10]	魏裕森,韦红术,张俊斌,等. 碳酸钙粒径匹配对储层保护效果的影响研究[J]. 长江大学学报(自科版), 2015, 12(2):51-54. WEI Yusen, WEI Hongshu, ZHANG Junbin,et al.The effect of calcium carbonate particle size matching on formation protection[J]. Journal of Yangtze University (Natural Science Edition), 2015, 12(2):51-54.
[11]	田荣剑, 罗健生, 王楠,等.钻井完井液储层损害室内评价关键技术[J]. 钻井液与完井液,2010, 27(6):16-19. TIAN Rongjian,LUO Jiansheng,WANG Nan,et al.Key technology of lab evaluation on reservoir damage of drilling and completion fluid[J]. Drilling Fluid & Completion Fluid,2010, 27(6):16-19.
[12]	丰全会, 储书平, 薛芸. MTZ油田保护油气层钻井液完井液技术[J]. 钻井液与完井液,2002, 19(3):27-29. FENG Quanhui, CHU Shuping, XUE Yun. Drilling fluid and completion fluid technology for formation protection in MTZ oilfield[J]. Drilling Fluid & Completion Fluid, 2002, 19(3):27-29.
