Study on Alkyl Polyglucoside Derivative Drilling Fluid and Its Use In Shale Gas Drilling
-
摘要: 昭通黄金坝YS108页岩气区块目的层为下志留统龙马溪组，岩性以灰色、黑色页岩为主，存在页岩地层易掉块垮塌，长水平段摩阻大、易卡钻，井眼清洁困难等技术难题。针对黄金坝页岩气水平井的地质和工程情况，研发并应用了以NAPG、CAPG和APG为核心主剂的烷基糖苷衍生物水基钻井液技术。NAPG聚醚胺基烷基糖苷是在APG分子上引入聚醚和胺基基团而制得，提升了抑制性、抗温性和润滑性等，CAPG阳离子烷基糖苷通过在APG分子上引入季铵盐阳离子基团而制得，提升了抑制性和抗温性等，他们通过吸附成膜、嵌入及拉紧晶层等可有效降低龙马溪岩屑的Zeta电位绝对值，降低岩屑活性。体系以APG为主润滑剂，以不同粒度级配（0.03~100 μm）纳米-微米封堵材料和烷基糖苷类小分子增稠剂满足昭通区块龙马溪页岩微孔微裂缝的封堵需求。该钻井液7.5 min中压滤失量为0 mL，高温高压滤失量不大于5mL，在密度2.30 g/cm3之内，极压润滑系数小于0.10，为强抑制、强封堵和高效润滑的钻井液体系，该体系解决了以上难题，实钻过程中井壁稳定，钻井液携砂及润滑性能良好，起下钻通畅，机械钻速较使用高性能水基钻井液的6口邻井和相邻区块井位提高14.6%~18.8%。该体系较好地满足了页岩气水平井钻井、完井施工技术要求。Abstract: The YS108 shale gas block is located in Huangjinba, Zhaotong, Yunnan Province, and the pay zone of this block is the Longmaxi formation of the lower Silurian series. The lithology of the pay zone is mainly gray, black shales which are easy to slough and collapse. In horizontal drilling, high friction and drag, pipe sticking and diffculties in hole cleaning are problems that have been frequently encountered. To mitigate these diffculties, an alkyl polyglucoside (APG) derivative drilling fluid was formulated with NAPG, CAPG and APG as the main additives. NAPG is a polyether amino APG made from APG by introducing polyether and amino groups into the APG molecular structure. NAPG has better inhibitive capacity, high temperature stability and lubricity. CAPG is made from APG by introducing quaternary ammonium group into the APG molecular structure. CAPG has better inhibitive capacity and high temperature stability. NAPG and CAPG effectively reduce the Zeta potential and hence the activity of shales. APG was used in the drilling fluid as the main lubricant, plugging agents of different sizes (0.03-100 μm) and low molecular weight alkyl glucoside viscosifer were used to satisfy the needs of plugging micro fractures found in the Longmaxi shales. This drilling fluid had 7.5 min API flter loss of 0 mL, HTHP flter loss≤5 mL. The extreme pressure friction coeffcient was less than 0.10 if mud density was less than 2.30 g/cm3. As a drilling fluid with strong inhibitive capacity, good plugging capacity and good lubricity, the APG derivative drilling fluid successfully helped solve the diffculties previously encountered. In feld application, gauge hole, good hole cleaning and good lubricity were obtained. Compared with 6 wells drilled nearby with high performance water base drilling fluids and wells drilled in an adjacent block, the well drilled with this drilling fluid had ROP increased by 14.6%-18.8%. The use APG derivative drilling fluid has satisfed the needs for horizontal shale gas drilling and well completion.
-
Key words:
- Shale gas /
- Horizontal well /
- Borehole stabilization /
- Alkyl polyglucoside /
- Water base drilling fluid
-
[1] 张琰, 艾双, 钱续军. MEG钻井液在沙113井试验成功[J]. 钻井液与完井液, 2001, 18(2):27-29.ZHANGYan, AI Shuang, QIAN Xujun, et al. Successful trial of MEG drilling fluid in Sha-113well[J]. Drilling Fluid & Completion Fluid, 2001, 18(2):27-29. [2] 雍富华, 余丽彬, 熊开俊, 等. MEG钻井液在吐哈油田小井眼侧钻井中的应用[J]. 钻井液与完井液, 2006, 23(5):50-52.YONG Fuhua, YU Libin, XIONG Kaijun, et al.Application of MEG drilling fluid in slim hole sidetracking wells[J].Drilling Fluid & Completion Fluid, 2006, 23(5):50-52. [3] 黄达全, 宋胜利, 王伟忠, 等. MEG钻井液在滨26X1井的应用[J]. 钻井液与完井液, 2008, 25(3):36-38.HUANG Daquan, SONG Shengli, WANG Weizhong, et al.The application of MEG drilling fluid in well Bin26X1[J].Drilling Fluid & Completion Fluid, 2008, 25(3):36-38. [4] 欧阳伟, 杨刚, 贺海, 等. MEG钻井液技术在剑门1井超长小井眼段的应用[J]. 钻井液与完井液, 2009, 26(6):21-23.OUYANG Wei, YANG Gang, HE Hai, et al.The application of meg drilling fluid in the long slim hole section of well Jianmen-1[J].Drilling Fluid & Completion Fluid, 2009, 26(6):21-23. [5] 赵虎, 甄剑武, 王中华, 等. 烷基糖苷无土相钻井液在卫383-FP1井的应用[J]. 石油化工应用,2012,31(8):6-9.ZHAO Hu, ZHEN Jianwu, WANG Zhonghua, et al.Application of alkyl polyglucoside clay-free drilling fluid in well Wei 383-FP1[J].Petrochemical Industry Application, 2012, 31(8):6-9. [6] 司西强, 王中华, 魏军, 等. 钻井液用阳离子烷基糖苷的合成研究[J]. 应用化工, 2012, 41(1):56-60.SI Xiqiang, WANG Zhonghua, WEI Jun, et al.Study on synthesis of cationic alkyl polyglucoside used in drilling fluid[J]. Applied Chemical Industry,2012,41(1):56-60. [7] 王中华. 2011-2012年国内钻井液处理剂进展评述[J]. 中外能源, 2013, 18(4):28-35.WANG Zhonghua.Review on development progress of the drilling fluid additives in china between 2011-2012[J]. Sino-Global Energy, 2013, 18(4):28-35. [8] 赵虎, 司西强, 雷祖猛, 等. 阳离子烷基糖苷钻井液在长南水平井的应用[J]. 精细石油化工进展, 2015, 16(1):6-9.ZHAO Hu, SI Xiqiang, LEI Zumeng, et al.Application of cationic alkyl glucoside drilling fluid in changnan horizontal wells[J].Advances in Fine Petrochemicals, 2015, 16(1):6-9. [9] 司西强, 王中华, 贾启高, 等. 阳离子烷基糖苷的中试生产及现场应用[J]. 应用化工, 2013, 42(12):2295-2297.SI Xiqiang, WANG Zhonghua, JIA Qigao, et al. Research on pilot production and field application of cationic alkyl glucoside[J].Applied Chemical Industry, 2013, 42(12):2295-2297. [10] 王玉满, 董大忠, 李建忠, 等. 川南下志留统龙马溪组页岩气储层特征[J]. 石油学报, 2012, 33(4):551-561.WANG Yuman, DONG Dazhong, LI Jianzhong, et al.Reservoir characteristics of shale gas in Longmaxi Formationg of the Lower Silurian, southern Sichuan[J]. Acta Petrolei Sinica, 2012, 33(4):551-561. [11] 赵虎, 司西强, 甄剑武, 等. 氯化钙-烷基糖苷钻井液页岩气水平井适应性研究[J]. 钻井液与完井液, 2015, 32(6):22-25.ZHAO Hu, SI Xiqiang, ZHEN Jianwu, et al.Study on adaptability of calcium chloride-alkyl polyglucoside drilling fluid to shale gas horizontal drilling[J].Drilling Fluid & Completion Fluid, 2015, 32(6):22-25. [12] 谢水祥, 蒋官澄, 陈勉, 等. 环保型钻井液体系[J]. 石油勘探与开发, 2011, 38(3):369-372.XIE Shuixiang, JIANG Guancheng, CHEN Mian, et al.An environment friendly drilling fluid system[J]. Petroleum Exploration and Development, 2011, 38(3):369-372. -
