Drilling Fluid Technology Used in Drilling Ultra Deep Well Datan-1 in Junggar Basin
-
摘要: 目前达巴松区块共完成11口探井,二开、三开使用的是钾钙基聚磺钻井液体系,在钻探过程中频繁出现缩径、垮塌、井漏、溢流等复杂事故,同时存在起下钻阻卡严重、钻井液受污染后性能极不稳定等问题。通过优选包被剂和添加胺基抑制剂,整体提高了体系抑制分散能力,解决了达探1井白垩系和侏罗系膏质泥岩极易水化膨胀造成井眼缩径垮塌的问题;通过利用体系强抑制、完善配方的封堵防塌能力、使用合理钻井液密度,杜绝了侏罗系西山窑组和八道湾组地层由于煤层发育容易发生垮塌、井漏的问题;通过KCl与NaCl的复配,提高体系的抑制性能和抗污染能力,体系回收率从原来的91.6%提高到97.5%,抗NaHCO3污染能力从5%提高至10%以上;优选复配合理的随钻堵漏剂和采用近平衡钻进,解决了可能发生的井漏问题。达探1井在井眼尺寸增大的情况下,钻井速度相比邻井大幅提升,平均机械钻速提高了35.48%;全井复杂事故率为零;各次完钻电测和下套管均一次成功;钻井月速为1105.86m/台月,较达1井提高51.23%,较达9井提高28.1%,较达10井提高48.12%。Abstract: 11 exploration wells have been completed in the Block Dabasong, the second and the third intervals of which were drilled with polymer sulfonate drilling fluid containing potassium and calcium salts. Tight hole, borehole wall collapse, mud losses,well flow, over-pull and sticking while tripping, and mud contamination etc. have been frequently encountered during drilling. To solve these problems, studies have been done to improve the properties of the polymer sulfonate drilling fluid used. A shale encapsulator and amine based inhibitor were used to improve the inhibitive capacity of the polymer sulfonate drilling fluid. The improved drilling fluid formulation was used to drill the well Datan-1, and was proved successful in solving the problems caused by the easy-to-hydrate-andswell Cretaceous and Jurassic gypsum-containing shales. Borehole instability and mud losses encountered in drilling the Xishanyao formation and the Badaowan formation were solved by the drilling fluid improved in inhibitive capacity and plugging performance, and by using more appropriatemud weight. Using a combination of NaCl and KCl, the percent recovery of shale cuttings was increased from 91.6%to 97.5%, and contamination tolerance of the drilling fluid was increased from 5%to 10%. Using well formulated LCM slurries and near-balanced drilling, possible mud losses can be prevented. Compared with offset wells, the well Dashen-1, which had larger hole sizes, had average ROP increased by 35.48%, and the monthly drilling rate was 1105.86 m per rig, 51.2%higher than that of the well Da-1, 28.1%higher than that of the well Da-9, and 48.12%higher than that of the well Da-10. No drilling problems were experienced during drilling, and the wireline logging and casing running were conducted with no delays.
-
[1] 吕志强,王书琪,尹达,等. 轮东1 井超深井钻井液技术[J]. 钻井液与完井液,2008,25(6):36-38.LYU Zhiqiang,WANG Shuqi,YIN Da,et al.The drilling fluid technology for ultra-deep well Lundong-1[J]. Drilling Fluid & Completion Fluid,2008,25(6):36-38. [2] 罗健生,李自立,李怀科,等.HEM 深水聚胺钻井体系研究及应用[J]. 钻井液与完井液,2014,31(1)20-23.LUO Jiansheng,LI Zili,LI Huaike,et al.Research and application of polyamine HEM deep water drilling fluid system[J]. Drilling Fluid & Completion Fluid,2014,31 (1):20-23. [3] 王中华. 超高温钻井液体系研究(Ⅰ)——抗高温钻井液处理剂设计思路[J]. 石油钻探技术,2009,37(3):1-6.WANG Zhonghua.Studies on ultra-high-temperature drilling fluid system(1):design ultra-high-temperature drilling fluid additives[J]. Petroleum Drilling Techniques,2009,37(3):1-6. [4] 崔贵涛,陈在君,黎金明,等. 复合盐水帝伤害钻井液在桃7-9-5AH 水平井的应用[J]. 钻井液与完井液,2011,28(3):42-44.CUI Guitao,CHEN Zaijun,LI Jinming,et al.Application of low damage composite salt drilling fluid in Tao 7-9-5 AH horizontal well[J]. Drilling Fluid & Completion Fluid,2011,28(3):42-44. [5] 胡德云,樊志刚,周成华,等. 伊朗雅达F7 井盐膏层钻井液技术[J]. 钻井液与完井液,2012,29(2):86-88.HU Deyun,FAN Zhigang,Zhou Chenghua,et al.Drilling fluid technology used in Salt-gypsum layer of Giada F7 well in Iran[J]. Drlling Fluid & Completion Fluid,2012,29(2):86-88. [6] 何振奎,李剑,孙中伟,等. 有机硅钻井液在河南张店油田的应用[J]. 钻井液与完井液,2009,26(4):75-77.HE Zhenkui,LI Jian,SUN Zhongwe i,et al. Application of organic silicone drilling fluid on Zhangdian oilfield of Henan[J]. Drilling Fluid & Completion Fluid,2009,26(4):75-77. [7] 何振奎. 页岩水平井斜井段强抑制强封堵水基钻井液技术[J]. 钻井液与完井液,2013,30(2):43-46.HE Zhenkui.Strong inhibiton and sealing water-based drilling fluid technology for deviated section of shale horizontal wells[J].Drilling Fluid & Completion Fluid,2013,30(2):43-46. [8] 赵利,郭延辉,李竞,等. 金河1 井有机盐氯化钾高密度钻井液技术[J]. 钻井液与完井液,2011,28(1):78-80.ZHAO Li,GUO Yanhui,LI Jing,et al.Application of organic KCl high-density drilling fluid technology in well Jinhe-1[J].Drilling Fluid & Completion Fluid,2011,28 (1):78-80. [9] 赵利,刘涛光,齐国中,等. 复合盐钻井液技术在莫116 井区的应用[J]. 钻井液与完井液,2012,29(1):33-36.ZHAO Li,LIU Taoguang,QI Guozhong,et al. Application on compound salt drilling fluid technology for wells in block Mo-116[J].Drilling Fluid & Completion Fluid,2012,29(1):33-36. [10] 范江,李晓光,张巨杰,等. 高密度KCl-聚合物钻井液在阿塞拜疆的应用[J]. 钻井液与完井液,2010,27 (5):44-46.FAN Jiang,LI Xiaoguang,ZHANG Jujie,et al. Application of high density KCl-polymer drilling fluid in Azerbaijan[J]. Drilling Fluid & Completion Fluid,2010,27(5):44-46. -
