Study and Application of Reservoir Protection Drilling Fluid Treated with Nano Spheres
-
摘要: 致密砂岩气藏具有特殊的储层特性,在钻井施工中极易受到损害,且损害难以解除。临兴区块是典型的低孔渗-致密、低丰度、不含硫干气气藏。为防止储层损害,在该区块钻井完井液中引入了封堵剂Micro-ball和CARB,API滤失量降至5mL以下,防塌、封堵性能优良,对易坍塌地层的岩屑回收率大于93%。纳米微球聚合物封堵剂Micro-ball是一种纳米级高分子聚合物,能对储层的微小喉道形成暂堵,可形成超低渗透率的内泥饼;多级惰性封堵剂CARB是一种粒径多级分布的可酸溶的惰性处理剂,其粒径范围一般大于储层孔喉,其在井壁表面可快速形成薄而脆的外泥饼,封堵效果好,泥饼易于清除。LX-xx5-1H井水平段采用裸眼-压裂方式完井,施工中该体系保持了良好的润滑性能,有效解决了钻进托压问题,未出现任何黏附钻具的情况;有良好的抗污染能力,性能稳定,维护简单;具有良好的流型和强抑制性,未发生坍塌掉块情况,多次起下钻十分顺利;压裂试气产量达到预期效果。Abstract: Tight sandstone gas reservoirs have special characteristics that make them quite prone to damage, which is very difficult to remove, during drilling. The dry gas reservoir in the Block Linxing, for example, is such kind of reservoirs, with low porosity, low permeability, low abundance, and no sulfur. To protect the reservoir from being damaged, two plugging agents, Micro-ball and CARB, have been used in the drill-in fluids to reduce the API filter loss to less than 5 mL. The Micro-ball is a high molecular weight polymer nano material able to penetrate into the pores in the reservoir formations to form interior mud cakes with ultra-low permeability, thereby to temporarily plug the micro pores. CARB is an acid-soluble inert spherical material with wide range of particle size distribution. CARB has particle sizes greater than the sizes of the pore throats in the reservoir formations, and are thus able to mud cakes on the surface of the formations. CARB has good plugging capacity and forms mud cakes that are easy to remove. The horizontal well LXxx5- 1H, completed with open-hole fracturing, was drilled with this drill-in fluid, which had good inhibitive capacity (shale cuttings percent recovery in hot rolling test is greater than 93%) and good plugging capacity. The improved lubricity of the drill-in fluid helped solve the problems of being unable to exert WOB during horizontal drilling, and balling of BHA. The drill-in fluid is resistant to contamination, has stable property which is easy to maintain, and good flow pattern. The drilling operation has been successful, and the gas production rate obtained after fracturing job is highly satisfactory.
-
[1] 腾学清,张洁,朱金智,等. 迪那3 区块致密砂岩气藏损害机理及储层保护技术[J]. 钻井液与完井液,2015,32(1):18-21.TENG Xueqing,ZHANG Jie,ZHU Jinzhi,et al. Permeability impairment and reservoir protection for tight sand gas reservoir in block Dina-3[J].Drilling Fluid & Completion Fluid,2015,32(1):18-21. [2] 李公让,蓝强,张敬辉,等. 低渗透储层水平井伤害机理及保护技术[J]. 石油钻探技术,2010,38(6):60-64.LI Gongrang,LAN Qiang,ZHANG Jinghui,et al.Low permeability reservoir horizontal well formation damage mechanism and formation protection[J].Petroleum Drilling Techniques,2010,38(6):60-64. [3] 姜瑞忠,王平国,卫喜辉,等. 国外致密气藏钻完井技术现状与启示[J]. 特种油气藏,2012,19(2):16-11.JIANG Ruizhong,WANG Pingguo,WEI Xihui,et al. Current status and enlightenments of overseas drilling and completion technology for tight gas reservoirs[J].Special Oil & Gas Reservoirs,2012,19(2):16-11. [4] 刘平均. 无土相低伤害暂堵钻井液体系在大牛地气田水平井应用概况[J]. 内江科技,2011(8):140-147. LIU Pingjun. Application of clay—free & low damage temporary plugging drilling fluid system in the horizontal section of Daniudi Gas field[J].NEI JIANG KE JI,2011(8):140-147. [5] 王伟吉,邱正松,黄维安,等. 纳米聚合物微球封堵剂的制备及特性[J]. 钻井液与完井液,2016,33(1): 33-36.WANG Weiji,QIU Zhengsong,HUANG Wei'an,et al. Preparation and characteristics of nano polymer microspheres used as plugging agent in drilling fluid[J]. Drilling Fluid & Completion Fluid,2016,33(1):33-36. [6] 屈沅治,孙金声,苏义脑. 纳米-膜结构新型水基钻井液技术研究[J]. 钻井液与完井液,2008,25(2):1-3.QU Yuanzhi,SUN Jinsheng,SU Yinao. Study on nanometer-membrane structured water base mud technology[J].Drilling Fluid & Completion Fluid,2008,25(2):1-3. [7] 赵雄虎,高飞,鄢捷年,等. 纳米钻井液材料GY-2 室内研究[J]. 油田化学,2010,27(4):357-359.ZHAO Xionghu,GAO Fei,YAN Jienian,et al. Laboratory research on nano-material gy-2 for drilling fluids[J].Oilfield Chemistry,2010,27(4):357-359. [8] 张婷,白小东,肖丁元,等. 纳米材料在钻井液中的应用研究进展[J]. 钻采工艺,2014,37(2):89-92.ZHANG Ting,BAI Xiaodong,XIAO Dingyuan,et al. Research on nano-materials used in drilling fluid[J]. Drilling & Production Technology,2014,37(2): 89-92. -
