Displace Open Hole Full of High Density OBM with WBM
-
摘要: 塔里木油田库车山前克深区块“库姆格列木群”层位岩性属于复合盐膏层，该盐膏层具有压力系数高、裸眼长、易塑性变形等特点，均用油基钻井液钻进。KS603井钻遇该层位中途完钻时发生井漏，为避免油基钻井液在下套管过程中出现恶性井漏，采用欠饱和盐水钻井液替换油基钻井液完成中完作业。施工过程中，在隔离浆中加入高碱比抗盐钙降黏剂碱液，利用碱液的稀释特性与OH-离子对油基钻井液中Ca2+的中和作用，使隔离浆始终保持较低黏切；因隔离浆中不能加入堵漏材料，在隔离浆之后的第一罐井浆中加入8%堵漏剂，提高井浆的防漏能力，避免替浆过程中发生井漏；为保证盐膏层井壁稳定，替浆密度为2.39 g/cm3，严格控制钻井液中的Cl-含量不小于1.8×105 mg/L，避免盐晶颗粒过多地溶入钻井液中，同时使用盐重结晶抑制剂NTA-2；下套管前进行承压堵漏作业。钻井液性能稳定，在中完作业过程中光钻铤、单扶、三扶、四扶通井、测盐层蠕变静止72 h后四扶通井、下套管、固井作业均一次性成功，井壁稳定、井下安全。Abstract: The lithology of the "Kumugeliemu Group" in the Block Keshen (Kuche piedmont structure) of the Tarim Oilfield is of compound salt and gypsum having high pressure coefficients. Long open hole drilling and plastic deformation of the formations penetrated made drilling very difficult. Oil base drilling fluids have long been used in the drilling operation. The well KS603 drilled in this area has experienced mud losses at the end of salt and gypsum drilling. To avoid losses of the expensive oil base drilling fluids during casing running, unsaturated brine muds have been used at the end of the drilling of the salt and gypsum formations. In displacing the oil base mud, a thinner solution with high concentration of alkalis is added into the spacer fluid in an effort to maintain a low viscosity of the spacer through the thinning effect of the alkali solution and the neutralization of calcium in the oil base drilling fluid with OH-. Since lost circulation material (LCM) cannot be added directly into the spacer, the first pit of mud displaced into the hole will be treated with 8% of LCM to avoid losses of the mud. To maintain the borehole stability of the salt and gypsum formations, the displacing mud will be weighted to 2.39 g/cm3, and the chloride maintained at no less than 1.8×105 mg/L to avoid the dissolution of formation salts. NTA-2 is used in the displacing mud to avoid salts from recrystallizing. Before running the casing strings, the compressive capacity of the weak points along the borehole is increased with LCMs to avoid mud losses during casing running. The properties of the displacing fluids have been proved stable by field operations. Wiper trips using drill strings with no centralizers, one centralizer, three centralizers, or four centralizers have been performed without a hitch. After 72 hours of waiting for logging the creeping of the salt and gypsum formations, a wiper trip with four-centralizer drill string, the casing running, and the well cementing have all been done right the first time. The borehole wall has remained stable during the operation, with no downhole troubles occurred.
-
于延雄,代一钦. 涪陵页岩气田油基钻井液防漏堵漏技术探讨[J]. 江汉石油科技,2015,25(1):33-36. YU Yanxiong,DAI Yiqin. Fuling oil-base drilling fluid plugging technology to explore shale gas field[J].Jianghan Petroleum Science And Technology,2015,25(1):33-36. 刘振通,李利军,宋元洪,等.KS204井盐膏层长封固段尾管固井技术膏盐层固井水泥技术[J]. 钻井液与完井液,2012,29(3):61-63. LIU Zhentong,LI Lijun,SONG Yuanhong,et al. KS204 well salt paste layer long cementing section of liner cementing technology in salt layer cementing cement technology[J].Drilling Fluid & Completion Fluid,2012, 29(3):61-63. 曹来顺.KCl欠饱和盐水钻井液在西部深井中的应用[J]. 胜利油田职工大学学报,2009,23(1)46-48. CAO Laishun.KCl undersaturated salt water drilling fluid applications in deep wells in western[J].Journal of Shengli Oil Field Worker University,2009,23(1):46-48. 刘振东,薛玉志,周守菊,等.全油基钻井液完井液体系研究与应用[J]. 钻井液与完井液,2009,26(6)10-12. LIU Zhendong,XUE Yuzhi,ZHOU Shouju,et al. All oil-base drilling completion fluid system research and application[J].Drilling Fluid & Completion Fluid,2009, 26(6):10-12. 何涛,李茂森,杨兰平,等.油基钻井液在威远地区页岩气水平井中的应用[J]. 钻井液与完井液,2012,29(3):1-5. HE Tao,LI Maosen,YANG Lanping, et al. Shale gas horizontal well, the application of oil-base drilling fluid in Hubei Weiyuan region[J].Drilling Fluid & Completion Fluid,2012,29(3):1-5. 杨晓冰,蔺志鹏,陈鑫,等.土库曼斯坦南约略坦洛坦复杂盐膏层钻井液技术[J].天然气工业,2011,31(7):55-58. YANG Xiaobing,LIN ZhiPeng,CHEN Xin, et al. Turkmenistan, south temple instead los temple complex salt-gypsum layer drilling fluid technology[J]. Natural Gas Industry,2011,31(7):55-58. 黄宏军,杨海军,蔺志鹏,等. 尤拉屯No.15井超高密度聚磺复合盐水钻井液技术[J]. 钻井液与完井液, 2009,26(5):10-13. HUANG Hongjun,YANG Haijun,LIN ZhiPeng,et al.Euler tuen No.15 wells, high density polyethylene sulfonated compound brine drilling fluid technology[J].Drilling Fluid &Completion Fluid,2009,26(5):10-13. -
