Discussion on the Mud Loss and Borehole Wall Collapse Prevention in Horizontal Drilling in Sulige Gas Field
-
摘要: 以往苏里格气田水平井水平段钻遇泥岩,通过提高钻井液密度实现力学平衡保持井壁稳定、防止坍塌。目前苏里格水平井进入整体开发阶段,地层压力因采气降低,高密度钻进时易造成井漏,堵漏作业难度较大并且易引起托压或黏附卡钻。针对提高密度易引起井漏的原因和特点,提出了以提高封堵性、保持一定抑制性和活度、合理降低钻井液ECD、采用合理的流变性和工程措施配合的方式预防井漏。分析了水平段常见泥岩类型和钻井液性能要求,对发生井漏后的措施进行了探讨。提出了做好低密度钻井液的防塌工作是防漏,在水平段为砂岩或泥岩较稳定下,可以降低密度与排量配合恢复正常;水平段漏失为压差性漏失,采用挤堵方式容易造成裂缝,与邻井串通而加重漏失;区别对待泥质砂岩、砂质泥岩、灰色泥岩和炭质泥岩,采取不同的钻井液性能的观点。Abstract: Borehole stabilization previously in horizontal drilling in Sulige gas field has been realized through increase in mud weight. Presently, the development of the Sulige gas field has entered a new stage of overall development in which formation pressure has been depleted because of gas production. Mud losses caused by high density and difficulties in controlling severe mud losses often led to inability to exert WOB and differential pressure pipe sticking. To prevent mud losses caused by high mud weight, several things have to be done, for example, improve the sealing and plugging performance of the drilling fluid, maintain the inhibitive capacity and activity of the mud filtrates, reduce the ECD to a certain level, and improve the mud rheology and use good engineering practices. The types of the mudstones commonly found in the horizontal section are analyzed, and requirements on drilling fluid studied. Measures for controlling mud losses are discussed. It is presented that to prevent borehole wall collapse, the important thing is to avoid mud losses. If sandstones are drilled in the horizontal section, or, if the mudstones encountered in the horizontal section is stable, mud weigh and flow rate can be reasonably reduced. Mud losses in the horizontal section are generally losses caused by differential pressures, and squeezing LCM slurries may induce new fractures in the formations, hence aggravating mud losses even into adjacent wells. For different formation lithology, such as argillaceous sandstone, sandy mudstone, gray mudstone and carbonaceous mudstone, different mud properties shall be adopted.
-
Key words:
- Horizontal gas well /
- Mud losses /
- Mudstone
-
罗宇峰,黄平,李茂森,等. 即时封堵防塌水基钻井液在四川页岩地层的应用[J]. 钻井液与完井液,2014, 31(5):28-31. LUO Yufeng, HUANG Ping, LI Maosen,et al. Application of instant plugging cave-in prevention drilling fluid in shale drilling in sichuan province[J].Drilling Fluid & Completion Fluid,2014,31(5):28-31. 陈福全, 夏荣徽, 聂强勇, 等.专项封堵防塌技术在塔中油田的应用[J]. 钻井液与完井液,2015,32(2):58-60. CHEN Fuquan,XIA Ronghui,NIE Qiangyong,et al. Application of special plugging and collapse prevention technology in Tazhong oilfield[J].Drilling Fluid & Completion Fluid, 2015,32(2):58-60. 徐加放, 邱正松, 黄晓东. 谈钻井液封堵特性在防止井壁坍塌中的作用[J]. 钻井液与完井液,2008,25(1):3-5. XU Jiafang,QIU Zhengsong,HUANG Xiaodong. Application of the sealing property of drilling fluids in bore hole stabilization[J].Drilling Fluid & Completion Fluid, 2008,25(1):3-5. 蔺志鹏, 陈恩让, 胡祖彪, 等. 杏平1水平分支井钻井液技术[J]. 钻井液与完井液,2007,24(2):15-18. LIN Zhipeng,CHEN Enrang,HU Zubiao, et al. Horizontal multi-lateral drilling fluid technology:well Xingping-1[J].Drilling Fluid & Completion Fluid, 2007, 24(2):15-18. 王伟良, 张雄雄, 田逢军, 等.固平28-21大位垂比水平井钻井液技术[J]. 钻井液与完井液,2015,32(2):89-92. WANG Weiliang, ZHANG Xiongxiong, TIAN Fengjun, et al. Drilling fluid technology for horizontal well Guping 28-21 of high horizontal displacement to vertical depth ratio[J]. Drilling Fluid & Completion Fluid, 2015,32(2):89-92. 陈金霞,阚艳娜,陈春来,等. 反渗透型低自由水钻井液体系[J]. 钻井液与完井液,2014,31(1):14-17. CHEN Jinxia,KAN Yanna,CHEN Chunlai, et al.Study and application of revers osmosis low free water drilling fluid[J]. Drilling Fluid & Completion Fluid, 2014, 31(1):14-17. 李凤杰,王多云,张庆龙,等. 鄂尔多斯盆地陇东地区延长组沉积相特征与层序地层分析[J]. 沉积学报, 2006,23(4):549-554. LI Fengjie, WANG Duoyun, ZHANG Qinglong, et al. Sedimentary facies characteristic and sequence stratigraphy analysis of Yanchang formation in Longdong Area,Ordos Basin[J].Acta Sedimentologica Sinica, 2006,23(4):549-554. 高辉,孙卫. 鄂尔多斯盆地合水地区长8储层成岩作用与有利成岩相带[J]. 吉林大学学报:地球科学版, 2010(3):542-548. GAO Hui,SUN Wei. Diagenesis and favorable diagenetic facies of Chang 8 reservoir in Heshui Area, Ordos Basin[J]. Journal of Jilin Unviersity:Earth Science Edition,2010(3):542-548. -
