Study on Filtration Property of Hypercritical CO2 Fracturing Fluid for Shale Reservoirs
-
摘要: 压裂施工过程中,压裂液的滤失量是影响压裂裂缝几何形态和压裂效果的主要因素,但目前中国还没有对页岩储层超临界CO2压裂液滤失规律实验方面的报道。因此,结合中国典型页岩气储层特征,研究了非线性滤失条件下,不同初始相态的CO2压裂液在地层岩心中的滤失规律,在此基础上分析了CO2压裂液滤失规律的主要影响因素,以及不同实验条件下CO2压裂液的滤失机理。实验结果表明,CO2压裂液的滤失规律受注入压力、压差、裂缝开启度及压裂液黏度等因素的影响,随着注入压力、压差、裂缝开启度的增大,CO2压裂液滤失速率增大;不同滤失实验条件下,影响CO2压裂液滤失规律的主导因素不同,当CO2压裂液处于超临界状态(7.38 MPa,31.1℃)时,由于黏度较大,超临界CO2压裂液的滤失系数相对较小。Abstract: Filter loss of fracturing fluid plays a major role in the geometry of fractures created by the fracturing fluid and the performance of fracturing. Reports on the filtration property of hypercritical CO2 fracturing fluid used in shale formation fracturing have not been found at present. Experiments have been conducted on shale reservoir cores (buried at 1,300-2,300 m, with natural fractures developed) taken from the Longmaxi Formation in Sichuan Basin, using a self-made filtration simulator, to study the filtration property of CO2 fracturing fluids with different initial phase states, at 55℃ and (confining pressure) 20 MPa, and different injection pressures and back pressures. Analyses of the experimental data indicate that in the conditions mentioned above, the filtration coefficient of CO2 fracturing fluids is between 1.00×10-4 m/min0.5 and 48.17×10-4 m/min0.5, with the spurt loss being negative. The filtration rate of CO2 fracturing fluid increases with increases in injection pressure, differential pressure, and the widths of fractures. The dominant factor affecting the filtration property of CO2 fracturing fluid in different conditions is different; at hypercritical state (7.38 MPa, 31.1℃), the CO2 fracturing fluid, because of its high viscosity, has a lower filtration coefficient.
-
Key words:
- Shale reservoir /
- Hypercritical CO2 /
- Fracturing fluid /
- Filtration property
-
李根生,王海柱,沈忠厚,等. 超临界CO2射流在石油工程中应用研究与前景展望[J].中国石油大学学报(自然科学版),2013(5):76-80. Li Gensheng,Wang Haizhu,Shen Zhonghou,et al. Application investigations and prospects of supercritical carbondioxide jet in petroleum engineering[J]. Journal of China University of Petroleum,2013(5):76-80. 王在明.超临界二氧化碳钻井液特性研究[D].东营:中国石油大学(华东)石油工程学院,2008. Wang Zaiming.Feature research of supercritical carbon dioxide drilling fluid[D].Dongying:College of Petroleum Enginnering in China University of Petroleum,2008. 杨发,汪小宇,李勇,等. 二氧化碳压裂液研究及应用现状[J]. 石油化工应用,2014,33(12):9-12. Yang Fa,Wang Xiaoyu,Li Yong,et al. Research and application status of carbon dioxide fracturing fluid[J]. Petrochemical Industry Application,2014,33(12):9-12. Tudor R,Poleschuk A.Low-viscosity,low-temperature fracture fluids[J].Journal of Canadian Petroleum Technology,1996,35(7):31-36. Hamdi Z,Awang M,Moradi B. Low temperature carbon dioxide injection in high temperature oil reservoirs[R].International Petroleum Technology Conference,2014,December 10. Tsakiroglou C D, Aggelopoulos C A, Terzi K A, et al. Effects of carbon dioxide leakages on shallow aquifer properties[R].SPE 164925,2013,June 10. 杨彪,李淑萍,于永. 裂缝性油藏降滤失压裂技术[J]. 低渗透油气田,2004,9(1):40-43. Yang Biao,Li Shuping,Yu Yong. Fluid loss fracturing technic of fractural reservior[J]. Low Permeability Oil &Gas Fluids,2004,9(1):40-43. 宋佳,卢渊,李永寿,等.煤岩压裂液动滤失实验研究[J]. 油气藏评价与开发,2011(Z1):74-77. Song Jia,Lu Yuan,Li Yongshou,et al. Experiment research on fracture fluid dynamic filtration of coal rocks[J]. Reservoir Evaluation and Development,2011(S1):74-77. 陈定珊. 压裂液滤失机理研究[J]. 石油钻采工艺,1986(3):77-80. Chen Dingshan. The mechanism researchof fracture fluid filtration[J]. Oil Drilling & Production Technology,1986(3):77-80. 苏伟东,宋振云,马得华,等.二氧化碳干法压裂技术在苏里格气田的应用[J]. 钻采工艺,2011(4):39-40. Su Weidong,Song Zhenyun,Ma Dehua,et al. Application of CO2 fracturing technology in su li ge gas field[J].Drilling & Production Technology,2011(4):39-40. 王鸿勋. 低黏压裂液的滤失与裂缝长度[J]. 华东石油学院学报,1980(2):17-23. Wang Hongxun. Modification of calculation equation for fracture length in case of low viscous fracturing fluid[J]. Journal of China University of Petroleum,1980(2):17-23. -
