Effect of Sealing and Plugging Capacity of Drilling Fluid on Borehole Stability of Weisan Member in Block Xuwen
-
摘要: 在徐闻区块钻井过程中,钻遇涠洲组时发生了井塌等井下复杂事故,但通过对测井数据和地层3个压力剖面数据分析,发现钻井使用的钻井液密度均高于地层坍塌压力当量密度,且涠三段地层层理裂隙比较发育。利用给出的坍塌压力当量钻井液密度简化计算式,计算了钻井液浸泡后岩心坍塌压力的变化,其结果表明,随着钻井液浸泡时间的增加,岩石强度下降,进而造成地层坍塌压力大幅度增加,岩心浸泡5 d坍塌压力增加了12.15%。对涠三段地层井壁失稳情况及影响因素进行了分析,认为该层位井壁失稳机理为:钻井液封堵性不足以阻止钻井液滤液侵入地层,造成地层强度下降和近井壁孔隙压力升高,进而导致地层坍塌压力升高,诱发井壁坍塌。采用有机盐、包被剂和胺基抑制剂改善了钻井液抑制性,采用ZHFD、QS-4和NFA-25作为封堵剂,形成了强封堵强抑制的有机盐胺基钻井液,延长了井壁坍塌周期,有效解决了涠三段井壁失稳的技术难题。Abstract: Borehole instability of the Weizhou Member has been encountered during drilling in Block Xuwen, although the mud weight used exceeded the equivalent density calculated from the collapse pressure of the formation, as known from logging data and analyses of 3 pressure profiles. It was found that fractures and fissures were developed in the Weisan Member. In laboratory experiments, cores taken from the formation of interest were immersed in drilling fluid, and changes in collapse pressure were calculated using a simplified equation of calculating mud weight from collapse pressure. It was found that the rock strength decreased with immersion time, resulting in a large increase in collapse pressure of formation; in the experiments, the collapse pressure increased by 12.15% after 5 d of immersion in drilling fluid. Analyses of borehole instability in the Weisan Member indicated that lack of sealing and plugging of formation by drilling fluid resulted in filtrate invasion, which in turn reduced the strengths of formation and increased the pressure of formations near the wellbore. The collapse pressure of formation was thus increased, resulting in borehole instability. Based on these understandings, the formulation of drilling fluid was modified by adding organic salts, encapsulators and amine additives into the drilling fluid, and using ZHFD, QS-4 and NFA-25 as plugging agents. With this optimized drilling fluid, the time required for the borehole to collapse was prolonged, and borehole instability of the Weisan Member was prevented.
-
刘贵林,宋碧涛,黄进军,等. 聚醚多元醇对泥页岩地层坍塌压力影响实验研究[J]. 复杂油气藏,2013, 6(3):64-66. Liu Guilin,Song Bitao, Huang Jinjun, et al. Effect of polyether polyol on collapse pressure of shale formation[J]. Complex Hydrocarbon Reservoir,2013,6(3):64-66. 徐江,石秉忠,王海波,等. 桥塞封堵裂缝性漏失机理研究[J]. 钻井液与完井液,2014,31(1):44-46. Xu Jiang, Shi Bingzhong, Wang Haibo, et al. Mechanism study on bridge plugging technology for fractured formation[J]. Drilling Fluid & Completion Fluid, 2014,31(1):44-46. 梁大川,罗平亚. 钻井液处理剂及其体系对泥页岩坍塌压力的影响研究[J]. 钻采工艺,2011,2:83-85. Liang Dachuan,Luo Pingya. Impact of drilling fluid and system on shale collapse pressure[J].Drilling & Production Technology,2011,2:83-85. Zhang W, Gao J, Lan K, et al. Analysis of borehole collapse and fracture initiation positions and drilling trajectory optimization[J]. Journal of Petroleum Science and Engineering, 2015, 129:29-39. 程远方, 张锋,王京印,等. 泥页岩井壁坍塌周期分析[J]. 中国石油大学学报,2007,31(1):63-66. Cheng Yuanfang,Zhang Feng, Wang Jingyin,et al. Analysis of borehole collapse cycling time for shale[J]. Journal of China University of Petroleum,2007,31(1):63-66 郑伟娟, 徐同台, 董晓军, 等. 延长气田石千峰组与石盒子组井壁失稳机理的研讨[J]. 钻井液与完井液, 2015,32(1):1-4. Zheng Weijuan, Xu Tongtai,Dong Xiaojun,et al. Study on borehole collapse drilling shiqianfeng and shihezi formations in yanchang gasfield[J]. Drilling Fluid & Completion Fluid,2015,32(1):1-4 洪有密. 测井原理与综合解释[M]. 石油大学出版社, 1993. Hong Youmi. Principle of logging and comprehensive interpretation[M].University of petroleum press,1993 Van Oort E. On the physical and chemical stability of shales[J]. Journal of Petroleum Science and Engineering, 2003, 38(3):213-235. 刘刚, 徐同台, 毛亚军, 等. 延长气田强抑制强封堵胺基钻井液技术[J]. 钻井液与完井液, 2014, 31(3):39-42. Liu Gang, Xu Tongtai, Mao Yajun, et al. Aminebased drilling fluid having high inhibitive and sealing capacities used in Yanchang gasfield[J]. Drilling Fluid & Completion Fluid,2014,31(3):39-42. Tan Q,Yu B,Deng J,et al.Study on wellbore stability and instability mechanism in piedmont structures[J].The Open Petroleum Engineering Journal, 2015,8(1):208-213. -
