Study on Low Damage Seawater Base Fracturing Fluids
-
摘要: 为了降低海上油田压裂施工成本,研究海水基压裂液并实现连续混配是一条重要的途径。研究合成了一种适应直接用海水配制的耐盐稠化剂BCG-1S,其抗Ca2+、Mg2+离子能力分别达到4000和2000 mg/L。在10℃下0.55% BCG-1S能在10 min内起黏,复配0.3%增黏剂B-55后,4 min内压裂液的性能就达到海洋平台海水连续混配的要求,并具有较好的携砂性能,30℃下单颗粒的沉降速率为0.0324 mm/s。评价表明,该压裂液的静态携砂性、稳定性能良好、抗温能力达到140℃;破胶彻底,残渣含量小于5 mg/L,破胶液表面张力小于26 mN/m,破胶液对支撑裂缝导流能力的伤害低至8.45%。该稠化剂具有良好的应用前景。Abstract: A salt-resistant thickening agent, BCG-1S, was developed for use inseawater base fracturing fluids.The BCG-1S is made from acrylamide, unsaturated functional monomers DM16 and AMP1 through polymerization and hydrolysis, using ammonium persulfate-sodium bisulfite as initiator.Below 10℃ 0.55%BCG-1S viscosities in 10 min.Settlent rate of single particle is 0.0324mm/s at 30℃.The viscosified tap water or seawater can tolerate contamination of 4, 000 mg/L Ca2+ and 2, 000 mg/L Mg2+.A seawater base fracturing fluid is formulated with the BCG-1S, BCG-5(a metallic ion chelator), B-55(a viscosifier), B-13(a high temperature stabilizer) and BCG-10(an encapsulated gel breaker) etc.This fracturing fluid has good carrying capacity and high temperature stability(up to 140℃).No sedimentation of solid particles is found in the fracturing fluid sample at 25℃ after 7 d, and the viscosity of the fluid remains almost unchanged.The fracturingfluid, after gel breaking, has residue content of less than 5 mg/L and surface tension of less than 26 mN/m, indicating thorough gel breaking.The flow conductivity of the fractures generated by this fracturing fluid is only reduced by 8.45%by the gel breaker solution used, which is acceptable.
-
宋爱莉,安琦,刘全刚,等. 海水基稠化剂的筛选与性能研究[J]. 石油天然气学报,2014,36(1):118-121. Song Aili,An Qi,Liu Quangang,et al.Screening and performance evaluation of seawater-based thickening agent[J].Journal of Oil and Gas Technology,2014,36(1):118-121. 何乐,王世彬,郭建春,等.海水中瓜尔胶溶胀性能研究[J]. 油田化学, 2014,31(2):207-210. He Le,Wang Shibin,Guo Jianchun,et al.Swelling performance of guar gum in seawater[J].Oilfield Chemistry, 2014,31(2):207-210. 刘刚芝,王杏尊,鲍文辉,等. 一种海水基压裂液体系的研究[J]. 钻井液与完井液,2013,30(3):73-75. Liu Gangzhi,Wang Xingzun,Bao Wenhui,et al. Research on seawater-based fracturing fluid technology[J]. Drilling Fluid & Completion Fluid,2013,30(3):73-75. 刘伟,刘建权.VES-80清洁压裂液实验研究[J]. 钻井液与完井液,2004,21(3):16-18. Liu Wei,Liu Jianquan.Laboratory research on clean fracturing fluid VES-80[J].Drilling Fluid & Completion Fluid,2004,21(3):16-18. Roddhart L P,Davics D R.Relation between chemistry and flow mechanics of borate-crosslinked fracturing fluids[J]. SPE 13905,1985. 刘通义. 新型抗高温清洁压裂液研究[D]. 成都:西南石油大学,2005:53-73. Liu Tongyi.Research on a new clean fracturing fluid with temperature resistance[D].Chengdu.Southwest Petroleum University,2005:53-73. 林波,刘通义,赵众从,等. 新型清洁压裂液的流变性实验研究[J]. 钻井液与完井液,2011,28(4):64-66. Lin Bo,Liu Tongyi,Zhao Zhongcong,et al.Experimental study on rheology of new clean fracturing fluid[J].Drilling Fluid & Completion Fluid,2011,28(4):64-66. 周际春. 抗高温清洁压裂液体系的研究[D]. 成都:西南石油大学,2008:42-47. Zhou Jichun.Study on properties of clean fracturing fluid with temperature resistance[D].Chengdu.Southwest Petroleum University,2008:42-47. 郭振. 海洋平台用压裂液连续混配技术研究[J]. 西部探矿工程,2014,3:38-42. Guo Zhen.Study on offshore platform with continuous mixing fracturing fluid technology[J].West-China Exploration Engineering,2014,3:38-42. 黄依理,杜彪,谢璇. 长庆油气田连续混配压裂液[J]. 油田化学,2009,26(4):376-378. Huang Yili,Du Biao,Xie Xuan.Continuously mixing fracturing fluid used in changqing oil/gas fields[J].Oilfield Chemistry,2009,26(4):376-378. -
