膨润土造浆率测定方法探讨

蔡利山; 杨健

doi:10.3969/j.issn.1001-5620.2015.05.023

膨润土造浆率测定方法探讨

doi: 10.3969/j.issn.1001-5620.2015.05.023

蔡利山¹,
杨健²

1.
中石化石油工程技术研究院, 北京
2. 中石化西南油气分公司钻井工程处, 成都

基金项目: 中石化科技部项目"页岩水平井水基钻井液技术研究与应用"(P13146)中的一部分。

详细信息

作者简介:
蔡利山,高级工程师, 1963年生, 2007年毕业于石油大学(华东)石油工程专业,现在从事钻井液技术的研究工作。地址:北京市朝阳区北辰东路8号北辰时代大厦5层510室;邮政编码100101;电话(010) 84988662;E-mail:942602768@qq.com。

中图分类号: TE254.3
计量
- 文章访问数: 648
- HTML全文浏览量: 143
- PDF下载量: 251
- 被引次数: 0
出版历程
- 收稿日期: 2015-04-09
- 刊出日期: 2015-09-30

Discussion on Determination of Yield of Bentonite

CAI Lishan¹,
YANG Jian²

Room 509, North Star Times Tower, No. 8 Beichen Dong Road, Chaoyang District, Beijing 100101, China

摘要

摘要: 造浆率是勘探行业用膨润土的主要技术指标,利用实验手段确定膨润土的造浆率指标时,事先需要进行大量的摸索性实验工作。由于受检土样技术参数不明确,实验人员操作经验存在差别,导致操作过程的盲目性很大,特别是人工处理实验数据的过程会造成明显误差,致使造浆率指标的测定过程比较繁琐,准确度不高,方法的可操作性较差。室内实验结果表明,利用Excel的趋势线拟合功能能够有效消除上述各环节中存在的误差,并且可以从根本上消除实验过程中的盲目性。实验数据的验证过程证实,以拟合趋势线方程计算得到的膨润土含量为基准配制悬浮液,测得的Fann35黏度计读数与理论值十分吻合,表明该方法可以快速而准确地确定膨润土的造浆率。
- 造浆率 /
- 趋势线拟合 /
- 膨润土 /
- 悬浮液 /
- 表观黏度 /
- 操作
Abstract: Yield is an important parameter of bentonite.The determination of this parameter is quite complex and time consuming. Lack of known properties of clay samples and difference in laboratory operator's skills play an important role in the success of the determination. Repeatability of determining the yield of bentonite is poor, and different persons measuring the yield of the same bentonite sample may give different results. It has been found that these problems can be mitigated or even eliminated using Excel's trend line fitting function. Validation of experiment data proves that clay suspension formulated with bentonite determined by the "trend line fitting" function has Fann35 readings closely agree with theoretical values, indicating that this method of yield determination is accurate and efficient.
- Yield /
- Trend line fitting /
- Bentonite /
- Suspension /
- Apparent viscosity /
- Operation

HTML全文

参考文献(4)

杨晋涛,范宏,卜志扬,等.蒙脱石的溶胀、蒙脱石水悬浮液及悬浮乳液的流变特性[J].硅酸盐学报, 2005, 33(12):1457-1463. Yang Jintao, Fan Hong, Bu Zhiyang, et al.Swellingbehavior of montmorillonite, rheological behavior of montmorillonite aqueous suspension and blend of suspension and emulsion[J]. Journal of the Chinese Ceramic Society, 2005, 33(12):1457-1463.

王厚亮,李建保,黄勇.膨润土的先进加工工艺和最新用途[J].中国矿业, 1996(6):39-43. Wang Houliang, Li Jianbao, Huang Yong.Advanced processing technologies and latest application of montmorillonite[J].China Mining Magazine, 1996(6):39-43.

张克勤,王欣,王奎才.国内外钻井液标准化工作综述(三)[J].石油钻探技术, 2001; 29(5):4-8. Zhang Keqin, Wang Xin, Wang Kuicai. The overview of standardization work on domestic and foreign drilling fluid (3rd)[J]. Petroleum Drilling Technology, 2001, 29(5):4-8.

曹丽文,温文富,王晚中.钠基膨润土造浆率实验研究[J].能源技术与管理, 2012(01):28-29. Cao LiWen, Wen Wenfu, Wang Wanzhong. Experiment Research on Mud Yielding Rate of Sodium Bentonite[J]. Energy Technology And Management, 2012(01):28-29.
