Study on and Application of a Polymeric Thickening Agent for Fracturing Fluid
-
摘要: 以分子间的静电作用为理论基础,研制出一种适用于中高温地层的阳离子型中高分子量的压裂液用聚合物稠化剂,通过红外光谱谱图以及核磁共振谱图分析聚合物结构,利用扫描电镜观察加入电吸引诱导剂后聚合物溶液空间结构的变化,并对该聚合物压裂液稠化剂进行性能测试,发现该压裂液聚合物稠化剂在加入电吸引诱导剂后可形成较强的空间网状结构,增黏效果很好,并且在110℃、130℃、170 s-1下剪切1 h后黏度保持在40~55 mPad s,在90℃条件下破胶时间为71.5 min,破胶后无残渣,岩心伤害率低,为12.07%。该压裂液表现出较强的黏弹性,携砂性能好,沉砂速率为1.96×10-4 m/min,且在砂比为60%时,常温下1 h后悬砂状态良好。该聚合物压裂液稠化剂满足现场压裂施工的要求,加之合成原料易得、价格较低,其现场应用前景广泛,通过在苏里格气田苏20-23-X井盒8下段的现场压裂施工测试中可以看出,其施工效果显著。Abstract: A cationic polymeric thickening agent used in fracturing fluid was developed for use in formations of middle or high temperature. Analyses of the thickening agent using IR spectrum, NMR and SEM showed that a spatial network was formed by the molecules of the polymer after reacting with an electric-attraction inducer, rendering the polymer very good thickening capacity. This polymer has viscosity between 40-55 mPa·s after shearing at 170 s-1 at 110℃ and 130℃ for 1 hour. Time for gel breaking was 71.5 minutes at 90℃. No residue was left after gel breaking, meaning that reservoir damage caused by this polymer would be very low (12.7% in an experiment.) Fracturing fluid formulated with this polymer showed very good viscoelasticity, and sand carrying capacity, rate of sand sedimentation being 1.96×10-4 m/min. At normal temperature, fracturing fluid containing 60% sands still showed good suspension stability after standing for 1 hour. As a cost-effective material, it satisfied the need for field fracturing operation, as shown in the fracturing of the lower segment of HE-8 in Well Su20-23-X, Sulige gas field.
-
Alfred R Jennings Jr.压裂液发展综述[J].吐哈油气, 2006, 1(4):71-76. Alfred R Jennings Jr.Summary of fracturing fluid[J]. Tuha Oil & Gas, 2006, 1(4):71-76. 陈馥,王安培,李凤霞,等.国外清洁压裂液的研究进展[J].西南石油学院学报, 2002, 24(5):65-68. Chen Fu, Wang Anpei, Li Fengxia, et al. Research progress of VES fracturing fluid abroad[J]. Journal of Southwest Petroleum University, 2002, 24(5):65-68. 林蔚然,黄凤兴,伊卓.合成水基压裂液增稠剂的研究现状及展望[J].石油化工, 2013, 42(4):451-456. Lin Weiran, Huang Fengxing, Yi Zhuo. Development and prospect of fracturing fluid' s thickening agent[J]. Petroleum Chemical Engineering, 2013, 42(4):451-456. 梁文利,赵林,辛素云.压裂液技术研究新进展[J].断块油气田, 2009, 164(1):95-98. Liang Wenli, Zhao Lin, Xin Suyun. The latest development of fracturing fluids systems[J]. Fault-Block Oil & Gas Field, 2009, 164(1):95-98. 罗平亚,郭拥军,刘通义.一种新型压裂液[J].石油与天然气地质, 2007, 28(4):511-515. Luo Pingya, Guo Yongjun, Liu Tongyi. A new type of fracturing fluid[J]. Oil & Gas Geology, 2007, 28(4):511-515. SY/T 6074-94《植物胶及其改性产品性能测定方法》[S]. SY/T 6074-94 Performance evaluation methods of Plant glue and their modified products[S]. SY/T 5107-2005《水基压裂液性能评价方法》[S]. SY/T 5107-2005 Performance evaluation methods of waterbased fracturing fluids[S]. SY/T 6276-1997《采油用聚合物凝胶强度的测定-流变参数法》[S]. SY/T 6276-1997 Evaluation of gel strength for oil recovery[S]. -
