新型螺旋除砂器的设计与应用研究

陈雷雷; 韩成才; 张高媛; 陈刚; 陈星晨; 邢建峰

doi:10.3969/j.issn.1001-5620.2015.04.024

新型螺旋除砂器的设计与应用研究

doi: 10.3969/j.issn.1001-5620.2015.04.024

1.
西安石油大学机械工程学院,西安
2. 西安宇星石油机械新技术开发有限公司,西安

详细信息

作者简介:
陈雷雷,在读硕士研究生,现在主要从事油田水处理系统的设计与研发工作。地址:陕西省西安市雁塔区电子二路18号西安石油大学本部陈刚(收);邮政编码710065;电话13772167081;E-mail:chengang891227@163.com。

中图分类号: TE357
计量
- 文章访问数: 528
- HTML全文浏览量: 110
- PDF下载量: 308
- 被引次数: 0
出版历程
- 收稿日期: 2015-01-29
- 刊出日期: 2015-07-31

Study on Design and Application of New Spiral Desander

No. 18 Dianzi Erlu, Yanta District, Xi’an Shiyou University, Xi’an, Shaanxi 710065, China

摘要

摘要: 目前油田使用的常规固-液分离设备无法对高含砂、大流量的砂-液混合物进行高效分离,为此设计了一种新型分离设备——螺旋除砂器。依据工程流体力学中的伯努利方程建立了螺旋除砂器相关结构参数的数学模型,利用MATLAB 软件对模型中的数据进行分析处理,确定其最优结构参数;根据具体结构尺寸,建立三维模型,利用FLUENT 流体仿真软件对其内部流场进行仿真分析。对比分析理论计算值与模拟仿真值,发现2 者之间偏差较小,进一步证明了螺旋除砂器结构设计的合理性。螺旋除砂器内部流场的仿真模拟,验证了螺旋除砂器对固-液两相混合物分离的可实现性,并为螺旋除砂器实际的设计制造提供了理论依据。
- 螺旋 /
- 除砂器 /
- 设计与研究
Abstract: Conventional solid-liquid separators commonly used in China are not able to efficiently deal with high flow rates sandliquid mixtures with high sand content. A new spiral desander was recently developed to tackle this problem. The design of this new desander involved the establishment of a mathematical model based on the Bernoulli equation to characterize the structure of the desander, the analyses of the data of the model using MATLAB® software to determine the optimum structural parameters, the setup of a three-dimensional model based on the structural parameters, and the simulation of the flow field inside the desander using the simulation software, FLUENT®. Comparison of theoretical calculations and simulation results showed that there were very few differences between the two, proving the validity and feasibility of the design. Simulation of the flow field inside the desander verified the feasibility of separating solid-liquid using spiral desander, and provided a theoretical basis for manufacturing spiral desander.
- Spiral /
- Desander /
- Design and study

HTML全文

参考文献(10)

祁鲁梁. 水处理工艺与运行管理使用手册[M]. 北京:中国石化出版社,2002. Qi Luliang.Water treatment process and operation management manual[M].Beijing :China Petrochemical Press,2002.

马永训. 油田采出水处理设计手册[M]. 北京:中国石化出版社,2005. Ma Yongxun.Design Manual for oilfield produced water treatment[M].Beijing :China Petrochemical Press,2005.

张惠,孙世刚. 螺旋式固液分离设备的分类及应用[J]. 大连大学学报,2004,25(4):41-46. Zhang Hui,Sun Shigang.Classification and application of the screw-type solid/liquid separating sets[J].Journal of Dalian University,2004,25(4):41-46.

郭烈锦. 螺旋管油气水多相流动与原油管流除砂理论[J]. 工程热物理学报,2002,23(1):107-110. Guo Liejin.The oil-gas-water three-phase flow and sand separation theories in helically coiled tubing separation technology[J].Journal of Engineering Thermophysics, 2002,23(1):107-110.

张也影. 流体力学[M]. 北京:高等教育出版社,1998. Zhang Yeying.Fluid mechanics[M].Beijing:Higher Education Press,1998.

刘保柱,苏彦华,张宏林.MATLAB7.0 从入门到精通[M]. 北京:人民邮电出版社,2012. Liu Baozhu,Su Yanhua,Zhang Honglin.MATLAB7.0 from entry to the master[M].Beijing :Posts & Telecom Press,2012.

鲁旭萍. 基于FLUENT 的新型旋流除砂器流场模拟分析及分离性能研究[D]. 重庆:重庆大学,2010. Lu Xuping.The numerical simulation and separation properties study of new-style hydrocyclone based on FLUENT[D].Chongqing :Chongqing University,2010.

唐家鹏.FLUENT 14.0 超级学习手册[M]. 北京:人民邮电出版社,2013. Tang Jiapeng.Super learning manual of FLUENT 14.0[M]. Beijing :Posts & Telecom Press,2013.

任连城. 基于CFD 的水力旋流器流场模拟研究[D]. 成都: 西南石油学院,2005. Ren Liancheng.Simulation of flow field of hydrocyclones based on CFD[D].Chengdu :Southwest Petroleum University,2005.

胥思平,朱宏武,张宝强. 固液分离水力旋流除砂器的数值模拟[J]. 石油机械,2006,34(3):24-27. Xu Siping,Zhu Hongwu,Zhang Baoqiang.Numerical simulation of solid-liquid separation for a hydrocyclone[J]. China Petroleum Machinery,2006,34(3):24-27.
