Recycling of Drilling Fluids in Sulige Gasfield
-
摘要: 苏里格气田地质施工条件满足钻井液工艺共通性,符合钻井液回收再利用工艺,分析了可再利用的GWSSL 钻井液体系特点。采用现场3 口井水平段不同时期钻井液取样以及实验室新配浆,结合现场施工周期特点,评价了钻井液在储备15 d 过程中的性能变化情况。结果表明,完钻钻井液若处理剂使用量充足,维护处理到位,在15d 的储存、倒运、再利用预设周期内,钻井液常规性能与完钻时基本保持一致,可利用成分所占比例高,且即使流变性出现变化,滤失量及膨润土含量在合理范围内,可用于稀释配浆改型。预计回收再利用1 m3 完钻钻井液,理论上可减少成本约300 元。钻井液回收再利用技术需配合使用好固控设备,保证完钻钻井液的品质,并配合KPAM 等抑制性絮凝剂的改型、维护,否则低密度固相的污染将影响钻井液性能的可控,甚至导致井下复杂。Abstract: Geological condition of the formations in Sulige Gasfield allows the use of drilling fluids with same formulation and properties, making possible the recycling of drilling fluid in multiple-well drilling. GWSSL is such a drilling fluid that can be reused in this area. Samples of drill-in fluids in horizontal drilling from 3 wells at different times and fresh drilling fluid made in laboratory were tested for their property changes over a period of 15 days. The test results showed that, given enough treatment of the drilling fluids with necessary additives, in 15 days, which was mandatory for the drilling fluid to be stored, transported, and reused, the samples had properties that were almost the same as that of the drilling fluid at well completion. Most of the drill-in fluid can be reused, some of them may need slight treatment, for example, dilution. It is estimated that recycling of 1 m3 drilling fluid would save 300 RMB Yuan. Using solids-control equipment to remove the unwanted solids, combined with treatment of the drilling fluids with high molecular weight flocculant, such as KPAM, the properties of the recycled drilling fluids will be easy to control.
-
Key words:
- Drilling fluid /
- Recycle /
- Recycle /
- Environment protection /
- Sulige Gasfield
-
赵向阳,林海,张振活,等. 长北气田钻井液回收重复利用实践与认识[J]. 钻井液与完井液,2013,30(1): 80-82. Zhao Xiangyang, Lin Hai, Zhang Zhenhuo, et al. Research on Recycle of Waste Drilling Fluid in Changbei Gas Field[J]. Drilling Fluid & Completion Fluid, 2013, 30(1): 80-82. 刘德胜,李昭辉,刘绪礼. 空气泡沫钻井液回收再利用技术[J]. 钻井液与完井液,2006,23(1):11-14. Liu Desheng, Li Zhaohui, Liu Xuli. Recovery and reuse of air-foam drilling fluid[J]. Drilling Fluid & Completion Fluid, 2006, 23(1):11-14. 赵凤臣,韦用红,金小文. 新型钻井液体系 GWSSL在苏里格水平井工厂化与标准化施工应用情况[J]. 长城钻井液,2014,1(1):15-18. Zhao Fencheng, Wei Yonghong, Jin Xiaowen. Application of new drilling fluid system GWSSL on sulige horizontal well factory and standardized drilling operation[J].Great Wall Drilling Fluid, 2014,1(1):15-18. 羊东晓. 塔河油田废弃钻井液回收利用经济性评价 [J]. 石油钻探技术,2004,32(3):73-74. Yang Dongxiao. The economic evaluation on recycling waste muds in tahe oilfield[J]. Petroleum Drilling Techniques, 2004, 32(3):73-74. 赵吉平,任中启,刘爱军. 废弃钻井物的二次利用和无害化处理[J]. 石油钻探技术,2003,31(1):37-39. Zhao Jiping, Ren Zhongqi, Liu Aijun. Reuse and harmless process of discarded drilling materials[J]. Petroleum Drilling Techniques, 2003, 31(1):37-39. 肖超,冯江鹏,宋明全,等. 尼日利亚边际油田合成基钻井液技术[J]. 钻井液与完井液,2009,26(6):80-81. Xiao Chao,Feng Jiangpeng,Song Mingquan,et al.Synthetic base drilling fluid technology for marginal oilfield in nigeria[J]. Drilling Fluid & Completion Fluid, 2009,26(6):80-81. 袁波,汪绪刚,宋建民,等. 艾哈代布油田废钻井液处理及循环利用技术[J]. 钻井液与完井液,2014,31(6): 92-94. Yuan Bo,Wang Xugang,Song Jianmin,et al. Treatment and recycling of waste drilling fluid in ahdeb oilfield[J]. Drilling Fluid & Completion Fluid,2014,31(6):92-94. -
