Development and Working Mechanism Analysis of a New Weak Gel Water Base Drilling Fluid
-
摘要: 目前弱凝胶钻井液存在抗温、抗盐和封堵性能差等问题,限制了其推广使用。研制出一种新的弱凝胶成胶剂,其抗温达150℃,抗钙可达4000 mg/L。以该成胶剂和优选出的降滤失剂IMPERMEX、封堵剂JA为主剂,以CX-215和KCl作抑制剂,形成了一种新型弱凝胶水基钻井液。评价结果表明:该钻井液在接近静止状态下的黏度可达90000mPa·s,剪切后黏度快速下降,且静切力表现出无时间依赖性,属于快的弱凝胶体系;具有好的降滤失和稳定井壁能力。环境扫描电镜和蔡司体显微镜分析结果表明,该钻井液微观结构由三维空间网状结构与包裹、镶嵌在网状结构节点上的溶胶颗粒组成,是一种具有独特空间结构的复杂胶体分散体系;该钻井液在微裂缝内能形成具有良好压缩性的致密封堵层,封闭岩石通道,具有良好的井壁稳定作用。Abstract: A new weak gel water base drilling fluid was formulated with a new developed weak gel agent as the main additive and other additives such as filter loss reducer, shale inhibitor and sealing and plugging agent selected through experiment. Laboratory experiment shows that this drilling fluid has unique rheological behavior, i.e., it has high viscosity at low shear rates, and weak gel is formed quickly within the fluid. This drilling fluid has very good filtration property and superior performance in shale inhibition. The properties of this drilling fluid remain stable at 150℃ or when contaminated by calcium of 4 000 mg/L. Study with SEM and Zeiss microscope shows that sol particles are encapsulated and embedded at the nodal points of a 3D network developed within the drilling fluid. This drilling fluid can form dense sealing layers with good compressibility in formations full of micro fractures or fissures, preventing water from entering into the formations, thus inhibiting the hydration and swelling of shale or formations with high content of clays.
-
Cobianco S. New solids-free drill-in fluid for low permeability reservoirs[C]. SPE 64979,2001. Dobson J W, Harrison J C,Hale A H,et al.Laboratory development and field application of a novel water-based drill-in fluid fo geopressured Horizontal Wells[C]. SPE 39098,2000. Bulter B A,Sharp K W,Mc-Daniel D R. New generation drill-in fluids and cleanup methodology lead to low-skin horizontal completions[R].SPE 58741,2000. 蔡利山,林永学,王文立. 大位移钻井液技术综述[J]. 钻井液与完井液,2010,27(3):1-13. Cai Lisan,Lin Yongxue, Wang Wenli.Review of drilling fluids for extend well[J].Drilling Fluid & Completion Fluid, 2010,27(3):1-13. 谢水详, 蒋官澄, 陈勉. 弱凝胶钻井液提切剂性能评价与作用机理[J]. 石油钻采工艺,2011,33(4):48-52. Xie Shuixiang,Jiang Guancheng,Chen Mian.Evaluation and mechanism of gel shear strength improving agent for dri lling fluid[J].Oil Drilling & Production Technology,2011, 33(4):48-52. 李颖颖,蒋官澄,宣扬,等.低孔低渗储层钻井液防水锁剂的研制与性能评价[J]. 钻井液与完井液,2014,31(2):48-52. Li Yingying,Jiang Guancheng,Xuan Yang,et al. Development and evaluation of water block prevention agent for drilling fluid used in low porosity low permeability reservoirs[J]. Drilling Fluid & Completion Fluid,2014,31(2):48-52. 苏雪霞,孙举,郑志军,等. 氯化钙弱凝胶无黏土相钻井液室内研究[J]. 钻井液与完井液,2014,31(3):48-52. Su Xuexia,Sun Ju,Zheng Zhijun,et al.Study on weak gel clay-free CaCl2 drilling fluid[J].Drilling Fluid & Completion Fluid,2014,31(3):48-52. Yamamoto K,Mitsuo Tamura,Goto N. Borehole Instability Analysis In Anistotropic And Heterogeneous Shale Formation[C],IADC/SPE 103883,2006. Javier S R, Lynden A. Interfacial slip violations in polymer solutions:role of microscale surface roughness[J]. Langmuir, 2003, 19(8):3304-3312. -
