Application of Drilling Fluid Technology in Drilling a Long Horizontal Section Well in Block Fengxi in Qinghai
-
摘要: 青海油田为实现稀井高产开发技术方案，在柴达木盆地大风山地区风西构造部署五口长裸眼水平井，并同时应用水基、油基钻井液进行施工对比，总结完善风西长裸眼长水平段水平井钻完井工艺技术模板。以优质复合盐水基钻井液在风西ⅠH1-5井的现场应用实例进行总结，并对相关钻井工艺技术应用、工程参数控制、流变性与携带等进行分析。风西ⅠH1-5井完钻井深为5478 m，水平段长2541 m，创青海油田水平段最长、油层钻遇率最高（100%）、水平井单趟进尺最多（1566 m）、水平段短程起下钻井段最长（达1000 m）、首次采用漂浮下套管技术等多项施工新纪录，该井的成功钻探对于超长水平段水平井的钻完井工艺在青海油田应用具有里程碑意义。与应用油基钻井液施工的邻井就钻井周期进行了对标分析，该优质复合盐水基钻井液施工井均优于油基钻井液施工井，对今后钻探长裸眼、长水平段水平井钻井液体系优选有较好的指导借鉴。Abstract: To obtain high production rate with less oil and gas wells, The Qinghai oilfield decided to drill five long open hole horizontal wells in the Fengxi structure which is located in the Dafengshan area in Qaidam Basin. Water-based and oil-based drilling fluids were to be used to drill these wells, and the results be compared to improve and perfect the technical prototype for future drilling and completion of long open hole and long horizontal section horizontal wells in the same area. This paper summarizes the field engineering of a high-quality compound saltwater drilling fluid on the well Fengxi IH1-5 and analyses are briefly conducted on the application, control of the engineering parameters, rheology and sand carrying capacity of the drilling fluid. The well Fengxi IH1-5, which is 5,487 m in depth, has a length of horizontal section of 2,541 m, the longest horizontal section in the Qinghai oilfield. This well has broken several records in this oilfield, such as penetrating the highest percentage of pay zones (100%), the longest footage (1,566 m) drilled in a single bit run, the longest horizontal section (1,000 m) in which short trips were performed, as well as the first application of casing floatation technology in casing running etc. The success of the drilling operation has milestone significance in applying the ultralong horizontal section well drilling technology in the Qinghai oilfield. Compared with the drilling operation of the offset wells drilled with oil-based drilling fluids, the use of this high-quality compound saltwater drilling fluid has gained better results in drilling than the oil-based drilling fluids previously used in other wells. The success gained in applying the water-based drilling fluid has provided a good guidance for optimizing the properties of water-based drilling fluids for horizontal wells with long open hole and long horizontal sections.
-
表 1 风西ⅠH1-5井复合盐水基钻井液的性能
井段 T热滚/
℃ρ/
g·cm-3FV/
sPV/
mPa·sYP/
PaGel/
Pa/PaFLAPI/
mLFLHTHP/
mL二开 100 1.45 46 16 4 1/1.5 2.4 11.6 三开 135 1.65 78 54 17.5 2.5/6 1.6 7.2 水平段 150 1.70 75 56 15 2.0/5.5 1.4 5.8
下载: 导出CSV
表 2 风西ⅠH1-5井二开现场实钻钻井液性能表
井段/m ρ/（g·cm-3） FV/s PV/mPa·s YP/Pa Gel/（Pa/Pa） FLAPI/mL FLHTHP/mL Kf MBT/（g·L-1） 451～2558 1.20～1.33 33～46 11～12 4.0～5.5 （0.5～1）/（2～8） 8.0～6.2 14.2～13.6 0.06～0.05 25～26 2558～2900 1.40～1.45 37～58 12～42 5.5～11.0 （2～5）/（2～8） 4.6～3.2 13.6～10.6 0.04～0.03 26～24
下载: 导出CSV
表 3 风西ⅠH1-5井三开现场实钻钻井液性能
井段/m ρ/（g·cm-3） FV/s PV/mPa·s YP/Pa Gel/（Pa/Pa） FLAPI/mL FLHTHP/mL Kf MBT/（g·L-1） 2900～3468 1.45～1.55 54～57 42～53 11.0～14.5 （2～4）/（2～4.5） 3.6～1.6 8.5～11 0.02～0.03 25～26 3468～4223 1.42～1.59 57～77 53～64 14.5～20.5 (2～4.5）/（2～7） 1.6～1.1 6～8 0.04～0.07 26～27 4223～5478 1.60～1.70 58～82 64～60 14.5～24.5 （2～7）/（4～10） 1.1～1.0 5～6 0.04～0.07 26～26 注：水平段测试FLHTHP在135 ℃测定。
下载: 导出CSV
表 4 风西油基、水基钻井液指标对标分析
井号 钻井液 井深/m 水平段
长/m钻井周
期/d水平段钻井
周期/d1 水基钻井液 5500 2537 62 24 2 水基钻井液 5478 2541 77 24 3 油基钻井液 5083 2100（−441） 69 22 4 油基钻井液 4718 1563（−978） 78 16 5 油基钻井液 4954 1474（−1067） 88 24
下载: 导出CSV
-
[1] 张永庶,韩秦鹏. 风西地区沉积储层特征[J]. 青海石油,2013,21(3):12-16.ZHANG Yongshu, HAN Qinpeng. Characteristics of sedimentary reservoirs in Fengxi area[J]. Qinghai oil March, 2013, 21(3):12-16. [2] 韩闯,李纲,别康,等. 二维核磁共振T1-T2谱在风西复杂碳酸盐岩储层流体识别中的应用[J]. 测井技术,2021,45(1):56-61.HAN Chuang, LI Gang, BIE Kang, et al. Application of innovative T1-T2 fluid typing method in complex carbonate reservoir of Fengxi block[J]. Well Logging Technology, 2021, 45(1):56-61. [3] 刘玉成,许小燕. 大风山油田沉积相研究[J]. 石化技术,2016,23(4):58-58.LIU Yucheng, XU Xiaoyan. Study on sedimentary facies in Dafengshan oilfield[J]. Petrochemical Industry Technology, 2016, 23(4):58-58. [4] 张民立, 王灿, 王信, 等. 抗240 ℃高温的高密度复合有机盐钻井液及其制备方法: CN201610766919.0[P]. 2016-08-30.ZHANG Minli, WANG can, WANG Xin, et al. National Invention patent, high-density composite organic salt drilling fluid resistant to 240 ℃ high temperature and its preparation method: CN201610766919.0[P]. 2016-08-30. [5] 王信,张民立,庄伟,等. 高密度水基钻井液在小井眼水平井中的应用[J]. 钻井液与完井液,2019,36(1):65-69. doi: 10.3969/j.issn.1001-5620.2019.01.013WANG Xin, ZHANG Minli, ZHUANG Wei, et al. Application of high density water base drilling fluid system in horizontal slim hole drilling[J]. Drilling Fluid & Completion Fluid, 2019, 36(1):65-69. doi: 10.3969/j.issn.1001-5620.2019.01.013 [6] 叶艳,安文华,尹达,等. 高密度甲酸盐钻井液配方优选及其性能评价[J]. 钻井液与完井液,2014,31(1):37-39,43.YE Yan, AN Wenhua, YIN Da, et al. Formulation optimization and performance evaluation of high-density formate drilling fluid[J]. Drilling Fluid & Completion Fluid, 2014, 31(1):37-39,43. [7] 侯杰,刘永贵,李海. 高性能水基钻井液在大庆油田致密油藏水平井中的应用[J]. 石油钻探技术,2015,43(4):59-65.HOU Jie, LIU Yonggui, LI Hai. Application of high-performance water-based drilling fluid for horizontal wells in tight reservoirs of Daqing oilfield[J]. Petroleum Drilling Techniques, 2015, 43(4):59-65. [8] 汪海,王信,张民立,等. BH-WEI完井液在迪西1井的应用[J]. 钻井液与完井液,2013,30(4):88-90.WANG Hai, WANG Xin, ZHANG Minli, et al. Applic-ation of BH-WEI completion fluid in well Dixi1[J]. Drilling Fluid & Completion Fluid, 2013, 30(4):88-90. [9] 王信,张民立,王强,等. 青海柴达木盆地三高井钻井液技术[J]. 钻井液与完井液,2016,33(6):45-50.WANG Xin, ZHANG Minli, WANG Qiang, et al. Drilling fluid technology for "three high" wells in qaidam basin in Qinghai[J]. Drilling Fluid & Completion Fluid, 2016, 33(6):45-50. [10] 张民立,庄伟,徐成金,等. 抗240 ℃高密度复合有机盐钻井液在翼探1井的应用[J]. 钻井液与完井液,2020,37(4):431-437.ZHANG Minli, ZHUANG Wei, XU Chengjin, et al. Application of ultra-high temperature high density compound organic salt drilling fluid in well Jitan-1[J]. Drilling Fluid & Completion Fluid, 2020, 37(4):431-437. [11] 李广冀,张民立,李树峰,等. 雁探1“四高”井钻井液应用技术[J]. 钻井液与完井液,2018,35(4):20-27.LI Guangji, ZHANG Minli, LI Shufeng, et al. Drilling fluid technology for"Four-High"well Yantan-1[J]. Drilling Fluid & Completion Fluid, 2018, 35(4):20-27. [12] 熊战,何悦峰,张闯,等. 青海油田深探井优快钻井关键技术[J]. 石油钻采工艺,2021,43(6):698-704.XIONG Zhan, HE Yuefeng, ZHANG Chuang, et al. Key technologies for optimized fast drilling of deep exploration wells in Qinghai oilfield[J]. Oil Drilling & Production Technology, 2021, 43(6):698-704. -
